Orange twist-on wire connectors in a pack of 100

Ideal

Ideal 30-073 twist-on wire cap connector orange 22-14 AWG 100 pack

SKU CH-J0SZ-GQW2R

Twist-on wire connectors for 22 to 14 AWG copper, 600 V rated, UL listed, pack of 100

  • TypeElectrical Wire Connector & Terminal Kits
  • Color/FinishOrange
  • Color MappingOrange
  • Connects 22-14 AWG copper wires securely
  • 600 V rating supports common circuits
  • 221 °F max temperature handles heat
  • UL Listed and CSA Certified for safety
  • Pack of 100 connectors covers many jobs

Twist-On Wire Connectors 22-14 AWG

The IDEAL 30-073 twist-on wire cap connectors join solid or stranded copper conductors in residential and light commercial wiring. Each orange polypropylene shell accepts wire sizes from 22 AWG up to 14 AWG. The package contains one hundred connectors for larger projects or ongoing maintenance work.

Spring Design and Safety Ratings

A zinc-plated steel spring inside each connector grips the conductors without the need for separate tools. The insulation carries a UL 94 V-2 flammability rating and the product is both UL Listed and CSA Certified for 600 volt maximum applications. Maximum operating temperature is 221 degrees Fahrenheit.

Capacity Range and Limitations

The connector handles a minimum combination of one 18 AWG with one 20 AWG wire and a maximum of two 14 AWG wires, with up to five conductors total per connector. It does not suit wire gauges larger than 14 AWG or installations requiring a higher voltage rating than 600 V.

Highlights

  • Connects 22-14 AWG copper wires securely
  • 600 V rating supports common circuits
  • 221 °F max temperature handles heat
  • UL Listed and CSA Certified for safety
  • Pack of 100 connectors covers many jobs

Specifications

TypeElectrical Wire Connector & Terminal Kits
BrandIDEAL
Color/FinishOrange
Color MappingOrange

Questions about this item

Will the steel contacts inside the orange 30-073 connector corrode over time and need replacing?

The contacts are zinc-plated steel; they resist oxidation under normal indoor use, so routine replacement is not expected unless the connector is exposed to moisture or corrosive atmospheres.

At what temperature does the polypropylene insulation on the 30-073 begin to soften during continuous loading?

The connector is rated for a maximum operating temperature of 221 degrees F; sustained currents that push the body beyond that point will cause the insulation to deform first.

How hot does the 30-073 get and does it hum when carrying 600 V all day?

The polypropylene body stays near ambient temperature at rated loads up to 600 V and the twist-on design has no moving parts, so it runs silently with no audible hum.
