ID TECH
ID TECH OMNI WCR3237-600US credit card reader
A USB barcode slot reader with a sealed design that reads up to three magnetic tracks and most barcode symbologies in a single swipe
- TypeBarcode Reader
- InterfaceUSB
- ColorBlack
- Read Speed5 to 65 IPS
- Head Duty Cycle (Passes)1,000,000
- FeaturePower Requirements: +5 VDC +/-10 %, 35mA Max Operating Tempe
- Reads up to three magnetic tracks per swipe
- Scans bar codes on paper, card stock or plastic
- Sealed slot design resists wear in heavy use
- USB connection with included cable for quick setup
- Operates from 32 °F to 131 °F for indoor environments
Magnetic-stripe and barcode slot reader
The ID TECH OMNI WCR3237-600US reads up to three tracks of magnetic data and most barcode symbologies in a single bi-directional swipe. A sealed slot protects the optics from debris in unattended kiosks and access-control points. USB connectivity and an included cable simplify integration with Windows, Linux or embedded controllers. Programmable output formats let the device match existing host protocols without firmware changes.
USB cable and programmable interface
The supplied USB cable provides both power and data, drawing a maximum of 35 mA at 5 VDC so no external supply is needed. Configuration software allows the integrator to tailor prefix, suffix, track separators and beeper tone to the host application. Three-colour LED and audible beeper give immediate swipe feedback for self-service users. Settings are stored in non-volatile memory and survive power cycles.
One-million-pass head duty cycle
The magnetic head is rated for 1 000 000 swipe cycles, a figure that determines whether the reader suits high-volume unattended deployments. Operating temperature spans 32 to 131 °F (0 to 55 °C) with up to 95 % non-condensing humidity. The unit measures 1.38 x 2.05 x 5.00 inches and weighs 1.40 lbs including the power pack. Buyers needing contactless NFC or chip-card acceptance must select a different device.
Highlights
- Reads up to three magnetic tracks per swipe
- Scans bar codes on paper, card stock or plastic
- Sealed slot design resists wear in heavy use
- USB connection with included cable for quick setup
- Operates from 32 °F to 131 °F for indoor environments
Specifications
| Brand | ID TECH |
|---|---|
| Series | OMNI |
| Model | WCR3237-600US |
| Type | Barcode Reader |
| Interface | USB |
| Color | Black |
| Read Speed | 5 to 65 IPS |
| Head Duty Cycle (Passes) | 1,000,000 |
| Feature | Power Requirements: +5 VDC +/-10 %, 35mA Max Operating Temperature: 32 to 131 degrees F (0 to 55 degrees C ) Storage Temperature: -31 to 158 degrees F (-35 to 70 degrees C ) Humidity: Maximum 95% non-condensing, dry storage Media Thickness: 0.005" (0.127 mm) to 0.050" (1.27 mm) Media Formats: UPC-A, UPC-E, EAN-8, EAN-13, Code 39, Telepen, In terleaved 2 of 5, Industrial 2 of 5, Code 128, MSI/Plessey, Codabar Slot Width: 0.055 (1.37 mm) Cable Length: 6-foot straight cable Cable Connector: TTL- 9 pin squeeze, Keyboard - 6 pin mini DIN, RS-232 - DE9F, TTL Mag/Bar Code Combo Readers-stri |
| Dimensions | 1.38" x 2.05" x 5.00" |
| Weight | 1.40 lbs. (including power pack) |
| Shipping weight | 0.45 kg |
| Package size | 203 × 203 × 178 mm |
Questions about this item
How many swipes can the magnetic head handle before it needs replacement?
The magnetic head is rated for one million passes, so it will last through very high-volume use before any service is required.
What is the maximum read speed of the barcode scanner?
The scanner reads barcodes at speeds from 5 up to 65 inches per second.
How much power does the reader draw from the USB port during all-day operation?
It requires 5 VDC at up to 35 mA, a very low draw that adds minimal heat to the host system.
