Square white LED downlight, thin cast-aluminium trim, edge-lit lens, remote driver box

Hubbell Incorporated

Hubbell Litebox Edge-Lit LED Downlight 8 inch square white 1750 lumens 20 watts

SKU CH-X641-1SHC1

Edge-lit square LED downlight with selectable colour temperature from 2700K to 4000K and 0-10V Triac dimming

  • Watts20
  • Selectable 2700K-4000K CCT with 90+ CRI for adaptable ambience
  • 1750 lumens at 20 watts delivers high efficacy illumination
  • Edge-lit polycarbonate lens eliminates bright spots and glare
  • Remote J-Box driver removes need for recessed housing
  • Universal 120-277V with 0-10V Triac/ELV dimming compatibility

Selectable Colour Temperature

This edge-lit LED downlight offers five selectable colour temperatures from 2700K to 4000K with a 90+ CRI rating. The 8 inch square white fixture produces 1750 lumens while drawing only 20 watts. It operates on universal 120-277V supply and supports 0-10V Triac/ELV dimming for commercial lighting control.

Replaces Recessed Housings

The remote J-box driver eliminates the need for an existing junction box or recessed housing entirely. This makes the luminaire ideal for new construction or remodel projects where plenum space is limited. It is rated for both IC and non-IC applications without requiring a separate housing can.

1750 Lumens From 20 Watts

The fixture delivers 1750 lumens at 20 watts, meeting CA Title 24 high-efficacy requirements for commercial installations. The integral diffuse polycarbonate lens provides uniform light distribution free of bright spots and low glare. It is not suited for buyers who need higher lumen output or larger aperture sizes beyond the 8 inch square format.

Highlights

  • Selectable 2700K-4000K CCT with 90+ CRI for adaptable ambience
  • 1750 lumens at 20 watts delivers high efficacy illumination
  • Edge-lit polycarbonate lens eliminates bright spots and glare
  • Remote J-Box driver removes need for recessed housing
  • Universal 120-277V with 0-10V Triac/ELV dimming compatibility

Specifications

BrandHubbell
Watts20

Questions about this item

What ceiling cut-out size does the 8 inch square Hubbell Litebox downlight require?

The fixture has an 8 inch square profile and uses a remote J-Box driver, so it mounts directly to the ceiling surface without a recessed housing or traditional cut-out.

How do I wire the remote driver box for 0-10V Triac dimming on 120-277V supply?

Connect the driver's line-voltage leads to the 120-277V circuit and run the low-voltage 0-10V control wires to a compatible dimmer; the step often missed is keeping Class 2 control wires separate from line-voltage conductors.

When should I expect to replace the LED module in this 20 watt, 1750 lumen downlight?

The integrated edge-lit LED array is not user-replaceable; the fixture is designed to maintain 90+ CRI output for its rated lifetime, after which the entire unit is replaced.
