Square white LED downlight with low-profile trim and diffuse lens

Hubbell Incorporated

Hubbell Litebox 8in Square LED Downlight White 1750lm 20W Selectable CCT

SKU CH-X1VG-6BY5M

Square 8-inch LED downlight delivers 1750 lumens at 20 watts with selectable 2700K to 4000K CCT and 0-10V Triac dimming

  • Watts20
  • Selectable CCT from 2700K to 4000K with 90+ CRI
  • 1750 lumens output using only 20 watts
  • Edge-lit design gives uniform light without bright spots
  • Low-profile half-inch trim fits tight plenum spaces
  • 0-10V Triac/ELV dimming on universal 120-277V

Hubbell Litebox 8in Square LED Downlight

The Hubbell Litebox is an 8-inch square LED downlight that delivers 1750 lumens at 20 watts. It features selectable colour temperature options of 2700K, 3000K, 3500K and 4000K with 90+ CRI. The fixture is sold as a case of six units finished in white.

Remote driver J-box and universal voltage

A metal remote driver J-box eliminates the need for an existing junction box or recessed housing. The unit operates on universal 120-277V input and supports 0-10V Triac and ELV dimming. Its half-inch surface profile suits new construction or remodel projects where plenum space is limited.

1750 lumen output with CA Title 24 compliance

The downlight produces 1750 lumens using 20 watts and meets California Title 24 high efficacy requirements. It is rated for IC and non-IC applications. Optional non-conductive decorative colour trims in white, black, silver and brushed oil-rubbed bronze are available separately for aesthetic customisation.

Highlights

  • Selectable CCT from 2700K to 4000K with 90+ CRI
  • 1750 lumens output using only 20 watts
  • Edge-lit design gives uniform light without bright spots
  • Low-profile half-inch trim fits tight plenum spaces
  • 0-10V Triac/ELV dimming on universal 120-277V

Specifications

Brandhubbell
Watts20

Questions about this item

How long can the 20-watt driver run before heat limits output?

The edge-lit design with integral polycarbonate lens and remote metal driver box spreads heat evenly, so sustained output at 1750 lumens is maintained without thermal throttling in IC or non-IC ceilings.

What noise or heat does the fixture produce during all-day operation?

The remote driver eliminates in-ceiling hum, the cast-aluminium trim stays cool to the touch, and the edge-lit panel runs silently with no fan or audible coil whine.

What wiring must already be in place for this downlight to work?

A 120-277 V circuit and a 0-10 V / Triac / ELV dimming pair are required; the remote J-box driver mounts to the supply cable, so no recessed housing or existing junction box is needed.
