White liquid-tight cord connector with stainless steel body, 1/2 in NPT thread

Hubbell Incorporated

Hubbell Incorporated SHC1022SS Liquid Tight Connector 1/2 in White

SKU CH-4YW7-JQAM2

Straight liquid-tight cord connector accepts 0.25 to 0.38 in cables into a 1/2 in NPT box opening with stainless steel body and white gland

  • TypeNPT
  • Length2.200
  • ColorWhite
  • Weight0.22
  • Liquid-tight seal protects cables from moisture ingress
  • Stainless-steel body resists corrosion in harsh environments
  • Straight 1/2 in NPT thread simplifies panel installation
  • White gland colour allows quick visual identification
  • UL and CSA listings confirm safety compliance

Hubbell SHC1022SS Liquid Tight Connector

The Hubbell SHC1022SS is a straight liquid-tight cord connector designed for a 1/2 in MNPT box connection. It accepts a single cord with a diameter range of .25 in to .38 in and is built from stainless steel with a white gland color code for identification. This new accessory suits installers needing a reliable seal in damp or wet locations.

Stainless steel body with white gland identification

The connector body is silver stainless steel while the gland carries a white color code, allowing quick visual confirmation during installation. Its straight style and 1 1/8 in length from box to end keep the profile compact inside enclosures. No external strain relief is fitted, so the cord relies on the gland compression for mechanical security. The unit weighs .22 and carries CSA LR27378 and UL E54218 (M) listings.

Sealed entry with no external strain relief

The liquid-tight design prevents moisture ingress at the box connection when the gland is properly tightened around the cord. Without external strain relief, pulling forces transfer directly to the compression seal, so installers must ensure adequate slack and support on the cable run. Power draw and noise are not applicable to this passive fitting, and thermal performance depends on the surrounding enclosure environment.

Highlights

  • Liquid-tight seal protects cables from moisture ingress
  • Stainless-steel body resists corrosion in harsh environments
  • Straight 1/2 in NPT thread simplifies panel installation
  • White gland colour allows quick visual identification
  • UL and CSA listings confirm safety compliance

Specifications

BrandHubbell Wiring Device-Kellems
ModelSHC1022SS
TypeNPT
Length2.200
ColorWhite
Weight0.22

Questions about this item

What does the 1/2 in MNPT box connection cap in practice?

The 1/2 in MNPT connection caps the maximum conduit or box opening size at 1/2 inch National Pipe Thread, limiting compatible enclosures to those with matching threads.

What physical clearance does the 2.200 in length and 1 1/8 in box-to-end dimension require?

The connector needs at least 2.200 inches of straight clearance from the mounting surface, with 1 1/8 inches extending inside the box for wiring space.

How is the stainless steel body installed on a 0.25 in to 0.38 in cord, and what step is often missed?

Slide the gland nut and sealing ring onto the cord, insert wires through the body, then tighten the gland nut to compress the seal; the step often missed is fully seating the sealing ring before final tightening.
