Blue nylon straight liquid tight connector with gray body 3/8 inch MNPT

Hubbell Incorporated

Hubbell Incorporated SHC1012CR Liquid Tight Connector 3/8 in Blue

SKU CH-75X1-T3DHM

Connects 0.38 in to 0.44 in cord to a 3/8 in MNPT box with 1.1 in length, insulated nylon body, blue gland, CSA LR27378 and UL E54218 listed

  • TypeLiquid Tight
  • ColorBlue
  • Liquid-tight seal protects cords from moisture
  • Blue gland colour simplifies circuit identification
  • Nylon construction resists impact and chemicals
  • Straight 3/8 in MNPT fit speeds panel mounting
  • 1 in overall length suits tight enclosures

Liquid-Tight Cord Connector

The Hubbell SHC1012CR is a straight nylon connector that secures a single cable to a 3/8 inch MNPT box entry. Its blue gland identifies the cord diameter range at a glance. The grey body provides insulated protection for indoor or outdoor junction boxes. This fitting suits electricians and installers terminating flexible cord in wet or damp locations.

Cord Diameter Limits

The connector accepts cables from .38 inch to .44 inch outside diameter and will not seal outside that window. No external strain-relief component is included, so the gland nut alone provides the grip and seal. The body projects 1.1 inches from the box face once installed. Installers must verify the cord falls within the stated range before specifying this part.

Capacity and Headroom

One cord is accommodated per connector, making it a single-circuit solution for control, signal or light-power leads. The nylon construction resists oil and moisture but is not rated for high-temperature or heavy-abrasion environments. CSA and UL listings cover the standard product; applications requiring external strain relief or multiple conductors need a different fitting.

Highlights

  • Liquid-tight seal protects cords from moisture
  • Blue gland colour simplifies circuit identification
  • Nylon construction resists impact and chemicals
  • Straight 3/8 in MNPT fit speeds panel mounting
  • 1 in overall length suits tight enclosures

Specifications

BrandHubbell Wiring Device-Kellems
ModelSHC1012CR
TypeLiquid Tight
ColorBlue

Questions about this item

Which cord diameter does the blue SHC1012CR accept?

The connector fits cords from .38 in to .44 in, so choose it when your cable falls inside that range.

What does the 1.1 in length mean once the connector is installed?

It measures 1.1 in from the box connection to the end of the connector, giving the installed protrusion.

What does the 3/8 in MNPT connection limit in practice?

It mates with a 3/8 in MNPT threaded entry, so the enclosure must provide that thread size.
