Hubbell Incorporated PLED96W-046-C2100-D 96W LED Ballast
Constant-current LED driver delivers 96 W at 2100 mA across 16–46 Vdc with IP66 and hazardous-location ratings
- Constant 2100 mA output drives LEDs without flicker
- 96 W maximum power suits high-output fixtures
- 100–277 V AC input works on standard supplies
- IP66 and NEMA 6 rating seals against dust and water
- UL Type HL rating permits hazardous-location installation
96W Constant-Current LED Driver
The Hubbell PLED96W-046-C2100-D is a 96W constant-current LED driver designed for industrial and hazardous-location lighting installations. It delivers a fixed 2100mA output across a 16 to 46Vdc range with dimming capability. The unit carries UL Type HL rating for hazardous locations alongside IP66 and NEMA 6 ingress protection. Its Black Magic Thermal Advantage aluminium housing supports a maximum case temperature of 90C and a minimum starting temperature of -30C.
Verify Input Voltage and Load Compatibility
Before ordering, confirm that the supply voltage at the installation site falls within the 100 to 277Vac nominal input range. The connected LED array must operate within the 16 to 46Vdc output window at 2100mA to avoid over-voltage or under-voltage conditions. Ensure the dimming control method matches the driver’s dimming specification and that the ambient environment does not exceed the 90C case-temperature limit. The driver is rated for dry and damp locations only.
Hazardous-Location Ready with Sealed Housing
The driver’s IP66 and NEMA 6 rated aluminium housing allows direct mounting in wet, dusty or corrosive areas without a separate enclosure. UL Type HL rating permits use in Class I, Division 2 hazardous locations where flammable gases or vapours may be present. The wide 100 to 277Vac input accommodates global supply voltages, reducing the need for multiple SKUs. Thermal management is handled by the integrated housing, freeing the installer from adding external heatsinks or forced-air cooling.
Highlights
- Constant 2100 mA output drives LEDs without flicker
- 96 W maximum power suits high-output fixtures
- 100–277 V AC input works on standard supplies
- IP66 and NEMA 6 rating seals against dust and water
- UL Type HL rating permits hazardous-location installation
Specifications
| Brand | Hubbell Lighting Components |
|---|
Questions about this item
What comes in the box and is any wiring or mounting hardware included?
The package contains the PLED96W-046-C2100-D driver in its Black Magic Thermal Advantage aluminum housing. Input and output wiring, connectors and mounting brackets are not included and must be sourced separately.
The spec lists 96 W output and 2100 mA constant current — how do I know this version matches my LED array?
Choose this driver only if your array operates between 16 and 46 Vdc and requires exactly 2100 mA; the 96 W rating is the maximum power the driver can deliver within that voltage window.
The driver is rated for 100-277 Vac input and IP66 — what does that mean when it is installed in a real fixture?
It will accept any mains supply from 100 to 277 Vac, run at case temperatures up to 90 °C, start at -30 °C, and its IP66 / NEMA 6 enclosure withstands powerful water jets and dust in hazardous-location fixtures.
