Rectangular aluminum LED driver housing, 96 watts

Hubbell Incorporated

Hubbell Incorporated PLED96W-034-C2800-D LED Driver 96W

SKU CH-QNQX-CDF3X

Constant-current LED driver delivering 2800 mA at 12-24 Vdc with 0-10V dimming, IP66/NEMA 6 housing and UL hazardous-location rating

  • typeElectrical Ballast
  • UL Type HL rated for hazardous locations
  • Thermal Advantage aluminium housing for heat dissipation
  • 2 W maximum output at 2800 mA constant current
  • 0-10 V and resistance dimming compatibility
  • IP66 and NEMA 6 rated for wet environments

Hubbell 96 W LED Driver

The Hubbell PLED96W-034-C2800-D is a constant-current LED driver rated for 96 watts maximum output. It supplies 2800 mA across a 12-24 Vdc range and accepts 100-277 Vac input. The aluminum housing carries UL Type HL rating for hazardous locations plus IP66 and NEMA 6 ingress protection. It suits installers who need a rugged, dimmable power supply for industrial or outdoor LED arrays.

Verify mains voltage and dimming method

Confirm the site supply falls within 100-277 Vac before ordering. The driver supports 0-10 V and resistance dimming; ensure the control system matches one of these schemes. Check that the LED load operates at 2800 mA and its forward voltage sits inside the 12-24 Vdc window. Ambient temperature must stay above -30 C for reliable starting.

Fits standard conduit and hazardous-area enclosures

The driver’s aluminum case dissipates heat without a fan, keeping maximum case temperature at 90 C and rated life temperature at 75 C. UL Dry and Damp Location rating plus IP66/NEMA 6 allow direct mounting in wet or dusty environments. Constant-current output removes the need for external current-limiting components, simplifying the wiring to the LED module.

Highlights

  • UL Type HL rated for hazardous locations
  • Thermal Advantage aluminium housing for heat dissipation
  • 2 W maximum output at 2800 mA constant current
  • 0-10 V and resistance dimming compatibility
  • IP66 and NEMA 6 rated for wet environments

Specifications

BrandHubbell
typeElectrical Ballast

Questions about this item

What comes with the PLED96W-034-C2800-D driver and is any extra wiring required?

The driver ships as a single unit in its aluminum housing. Input and output leads are factory-fitted; no separate cables or connectors are included.

How do I choose between the available current or voltage versions of this driver?

This model is fixed at 2800 mA output current and 12-24 Vdc output voltage. Select it only when your LED array matches both values.

What does the 95.2 W maximum output mean once the driver is installed in a fixture?

It is the highest continuous power the driver can deliver to the LEDs. The case temperature must stay at or below 75 °C for rated life and must never exceed 90 °C.
