Rectangular aluminum LED driver housing with cable glands

Hubbell Incorporated

Hubbell Incorporated PLED96W-030-C3150-D 96 W ballast

SKU CH-VBWW-5ZXT8

Constant-current 96 W LED driver delivering 3150 mA at 10-30 Vdc with 0-10 V dimming, IP66 enclosure and UL Type HL hazardous-location rating

  • UL Type HL rating suits hazardous locations
  • 3150 mA constant current output drives LEDs precisely
  • 0-10 V dimming enables smooth light control
  • IP66 and NEMA 6 sealing resists water and dust
  • Aluminium housing with thermal advantage manages heat up to 90 °C

96 W Constant-Current LED Driver

The Hubbell PLED96W-030-C3150-D supplies a fixed 3150 mA output across a 10-30 Vdc range for LED arrays that require precise current regulation. It accepts a universal 100-277 Vac nominal input, making it suitable for commercial and industrial lighting installations worldwide.

0-10 V Dimming and Thermal Housing

An integrated 0-10 V resistance dimming interface allows compatible controls to adjust light levels without external modules. The Magic Thermal Advantage aluminium housing manages heat so the driver operates up to a 90 °C maximum case temperature and starts reliably at -30 °C.

UL Type HL Hazardous-Location Rating

The driver carries UL Type HL approval and meets IP66 and NEMA 6 ingress protection, permitting installation in classified hazardous areas where flammable gases or dust may be present. Buyers who need a non-hazardous-rated or non-dimmable unit should select a different model.

Highlights

  • UL Type HL rating suits hazardous locations
  • 3150 mA constant current output drives LEDs precisely
  • 0-10 V dimming enables smooth light control
  • IP66 and NEMA 6 sealing resists water and dust
  • Aluminium housing with thermal advantage manages heat up to 90 °C

Specifications

BrandHubbell

Questions about this item

Will the aluminium housing need any maintenance to keep its thermal advantage over time?

The sealed IP66 aluminium housing has no user-serviceable parts and is designed to dissipate heat without routine maintenance.

What limits continuous full-load operation before the driver shuts down?

The case temperature limit is 90 °C; sustained loads that push the housing above this point will trigger thermal protection.

How much heat and power draw should I expect when the driver runs at 96 W all day?

At full load it draws 96 W from the mains and delivers up to 94.8 W to the LEDs, with the difference appearing as heat inside the IP66 housing.
