Gray rectangular duplex receptacle with two vertical slots and a round ground hole, smooth thermoplastic face, flush-mount design

Hubbell Incorporated

Hubbell Incorporated HBL8300GY 20A 125V Duplex Receptacle Gray

SKU CH-D6KJ-DAWW5

A hospital-grade 20A 125V duplex receptacle with impact-resistant face, nickel-plated bypass contacts, four-point grounding, and back/side wiring for #12–#10 AWG copper

  • Color MappingGray
  • TypeWiring Devices
  • Hospital-grade safety backed by UL 498 and CSA C22.2 No.42 compliance
  • Reliable conductivity through nickel-plated brass bypass contacts
  • Four-point grounding system enhances electrical fault protection
  • Impact-resistant thermoplastic polyester face withstands -40°F to 167°F operation
  • Flexible installation with back and side wiring for #12–#10 AWG copper wire

Hospital-Grade Duplex Receptacle

The Hubbell HBL8300GY is a 20A 125V NEMA 5-20R duplex receptacle built to hospital-grade UL 498 requirements. It features a deep-body design with an impact-resistant thermoplastic polyester face and nickel-plated brass bypass contacts. Four-point grounding and a circuit ID marking area support reliable installation in designated healthcare areas.

Flush-Mount Commercial Installations

This device suits electricians and facility managers wiring patient-care areas, laboratories or other locations that demand hospital-grade listing. Back and side screw terminals accept #12–#10 AWG solid or stranded copper for flexible rough-in. It is not for circuits requiring GFCI protection or configurations other than NEMA 5-20R.

NEMA 5-20R 20A 125V Rating

The single specification that decides fit is the NEMA 5-20R configuration rated 20 amps at 125 volts AC. The receptacle is certified to CSA C22.2 No. 42, Federal Specification W-C-596, NEMA WD-6 and UL 498, with an operating range of -40 °F to 167 °F.

Highlights

  • Hospital-grade safety backed by UL 498 and CSA C22.2 No.42 compliance
  • Reliable conductivity through nickel-plated brass bypass contacts
  • Four-point grounding system enhances electrical fault protection
  • Impact-resistant thermoplastic polyester face withstands -40°F to 167°F operation
  • Flexible installation with back and side wiring for #12–#10 AWG copper wire

Specifications

BrandHUBBELL WIRING DEVICE-KELLEMS
Color MappingGray
TypeWiring Devices

Questions about this item

Will the #12–#10 AWG screw terminals need re-torquing after years of thermal cycling?

The back and side wired screw terminals accept #12–#10 AWG copper wire; periodic inspection and re-torquing to the manufacturer’s specification is recommended for long-term reliability.

What is the maximum continuous current the NEMA 5-20R contacts can carry before temperature rise becomes the limiting factor?

The receptacle is rated 20 A at 125 V AC; sustained loads at or near 20 A will cause the contact temperature to approach the 167 °F (75 °C) operating limit first.

How warm does the thermoplastic polyester face get when the outlet runs at 20 A all day?

At full 20 A load the device operates within its rated -40 °F to 167 °F (-40 °C to 75 °C) range, so the face temperature will not exceed 167 °F under normal conditions.
