Black oval flanged locking receptacle with screw terminals

Hubbell Incorporated

Hubbell Incorporated HBL7596 Midget Flanged Locking Receptacle ML-2R video accessory

SKU CH-SVRA-2H6FA

A 15 A, 125 V AC locking receptacle with an oval stainless-steel flange and screw-terminal wiring

  • TypeLocking Devices
  • ColorBlack
  • 15 A current rating powers demanding video accessories
  • 125 V AC voltage rating matches standard AV equipment
  • ML2-15R NEMA configuration ensures correct plug fit
  • Stainless steel housing resists wear in rack environments
  • Screw terminals provide secure wire connections

Hubbell HBL7596 Locking Receptacle

The Hubbell HBL7596 is a midget flanged locking receptacle rated for 15 A at 125V AC. It is designed for industrial or commercial equipment requiring a secure, polarized connection that resists accidental disconnection. The unit features a straight orientation and a grounded two-pole, three-wire configuration suitable for standard single-phase power distribution.

NEMA ML2-15R Configuration

This receptacle uses the NEMA ML2-15R configuration, which determines pin spacing and blade geometry for mating plugs. The brass contacts and screw-terminal wire connections accept standard wiring for a 15 A circuit. The stainless steel housing carries a NEMA 1 enclosure rating for indoor use.

Flanged Panel Mount Installation

The oval flanged body mounts directly to a panel or enclosure with screws through the flange holes. Wiring is completed via screw terminals on the rear, requiring a screwdriver and proper torque. No cover is included, so the installer must provide environmental protection if the mounting location demands it. Buyers who need a weatherproof cover or a higher amperage rating should select a different device.

Highlights

  • 15 A current rating powers demanding video accessories
  • 125 V AC voltage rating matches standard AV equipment
  • ML2-15R NEMA configuration ensures correct plug fit
  • Stainless steel housing resists wear in rack environments
  • Screw terminals provide secure wire connections

Specifications

BrandHubbell Wiring Device-Kellems
ModelHBL7596
TypeLocking Devices
ColorBlack

Questions about this item

What does the 15 A rating mean for my circuit?

The receptacle is rated for 15 A at 125 V AC, so it can carry a continuous load up to that level on a properly protected branch circuit.

How does the ML2-15R configuration limit what I can plug in?

The NEMA ML2-15R locking layout only accepts matching ML-2P plugs, preventing standard straight-blade connectors from mating.

What mounting holes does the oval flange need?

The single-gang oval flange mounts to a standard device box using the two countersunk screw holes on the flange face.
