Gray flanged inlet with stainless steel flange and black housing, two blades, mounting hardware included

Hubbell Incorporated

Hubbell Incorporated HBL7467 15A Midget Locking Flanged Inlet 2P 2W video accessory

SKU CH-7CAW-GFQTB

A 15 A, 125 V AC midget locking flanged inlet with stainless-steel flange and housing, accepting 18–14 AWG wire and including mounting hardware

  • Type2 Pole 2 Wire
  • ColorGray
  • 15 A rated inlet powers equipment reliably
  • Midget locking design secures connections against vibration
  • Stainless steel flange resists corrosion in harsh environments
  • IP20 enclosure protects internal contacts from debris
  • Accepts 18 to 14 AWG wire for flexible installation

15 A Midget Locking Inlet

The Hubbell HBL7467 is a 15 A midget locking flanged inlet designed for single-phase 125 V AC circuits. It accepts two-pole, two-wire connections and includes stainless-steel mounting hardware for panel installation.

Wiring and panel checks

Verify that your supply conductors fall between 18 AWG and 14 AWG and that the panel cut-out matches the flanged profile. The inlet is non-grounded, so ensure your circuit protection and wiring scheme comply with local code for two-wire loads.

Sustained-load behaviour

Rated for continuous operation at 15 A with heat-resistant materials and an IP20 enclosure, the inlet maintains stable contact resistance during extended duty cycles. Stainless-steel housing and flange resist corrosion in indoor environments where prolonged power draw is expected.

Highlights

  • 15 A rated inlet powers equipment reliably
  • Midget locking design secures connections against vibration
  • Stainless steel flange resists corrosion in harsh environments
  • IP20 enclosure protects internal contacts from debris
  • Accepts 18 to 14 AWG wire for flexible installation

Specifications

BrandHubbell Wiring Device-Kellems
ModelHBL7467
Type2 Pole 2 Wire
ColorGray

Questions about this item

What does the HBL7467 flanged inlet include for installation?

The unit includes mounting hardware. A stainless-steel flange and housing are built in, and the gray inlet accepts 18 to 14 AWG conductors.

Which NEMA configuration does this inlet accept?

It is keyed for the ML1-15P midget locking plug, rated 15 A at 125 V AC, single phase, two-pole two-wire non-grounded.

What does the 15 A rating mean when the inlet is wired in a rack?

The 15 A rating is the continuous current limit at 125 V AC; conductors must be 14 AWG maximum and the IP20 enclosure provides finger protection only.
