Hubbell Incorporated HBL2616 Flanged Locking Receptacle L5-30R 30 A 125V AC White video accessory
A flanged locking receptacle rated 30 A at 125V AC with a white nylon housing and screw terminals
- TypeLocking Devices
- Length3.000
- ColorWhite
- Weight0.1
- L5-30R configuration ensures a secure 30 A connection
- 125 V AC rating supports standard single-phase power
- Nylon housing provides durable insulation in white finish
- Flanged flush-mount design simplifies panel installation
- Brass screw terminals deliver reliable wire termination
Locking Receptacle for 30 A Circuits
This flanged locking receptacle provides a secure NEMA L5-30R connection rated for 30 amps at 125 volts AC. Its nylon housing and brass contacts are built for reliable power delivery in fixed installations. The straight orientation and screw terminals simplify wiring for electricians and installers. A white finish matches standard panel aesthetics.
Suited for Single-Phase Equipment Hookups
Installers connecting single-phase loads up to 30 amps will find the polarised three-wire design matches the L5-30R specification. The flush-mount round flange fits a single-gang opening without a cover. Buyers who need a different NEMA configuration, a higher voltage rating, or a shrouded housing should look at other models.
Stable Contact Under Continuous Load
Brass screw terminals maintain consistent contact resistance when the circuit runs at the full 30 amp rating over long periods. The nylon housing resists heat and impact without deforming. NEMA Type 1 enclosure rating confirms protection against incidental contact in indoor environments. No moving parts mean performance does not degrade with repeated mating cycles.
Highlights
- L5-30R configuration ensures a secure 30 A connection
- 125 V AC rating supports standard single-phase power
- Nylon housing provides durable insulation in white finish
- Flanged flush-mount design simplifies panel installation
- Brass screw terminals deliver reliable wire termination
Specifications
| Brand | Hubbell Wiring Device-Kellems |
|---|---|
| Model | HBL2616 |
| Type | Locking Devices |
| Length | 3.000 |
| Color | White |
| Weight | 0.1 |
Questions about this item
What mounting style does the HBL2616 flanged locking receptacle require for installation?
The HBL2616 uses a flush mount type, meaning the flange sits flat against the panel or enclosure surface and is secured with screws through the round flange holes.
Will the L5-30R receptacle accept the 30 A 125 V AC plug from my existing generator cord set?
Yes, the NEMA L5-30R configuration matches a standard 30 A 125 V AC locking plug with two poles and three wires, so your existing cord set will lock securely into this receptacle.
How can I verify the receptacle is wired correctly after installation?
With power off, confirm the brass screw terminals show proper polarity — hot on the narrow blade side, neutral on the wide blade side, and ground on the grounding terminal — then energise and measure 125 V AC between hot and neutral with a multimeter.
