Black industrial locking receptacle with twist-lock face and flush-mount hardware

Hubbell Incorporated

Hubbell Incorporated HBL2430 Locking Receptacle L16-20R 20 A 480V video accessory

SKU CH-ED2R-EX5RV

A 20 A, 480 V AC locking receptacle with twist-lock mechanism for three-phase industrial power, flush-mounted with brass contacts and nylon housing

  • TypeLocking Devices
  • ColorBlack
  • Industrial-grade locking connection with NEMA L16-20R twist-lock design
  • Reliable 20 A, 480 V AC three-phase power delivery
  • Secure wiring accepts #16 to #8 AWG copper conductors
  • Durable nylon housing with brass contacts withstands -40 °C to +75 °C
  • UL 498 listed and CSA C22.2 No. 42 certified for safety

Industrial 20 A 480 V Twist-Lock Receptacle

The Hubbell HBL2430 is a NEMA L16-20R locking receptacle rated for 20 amps and 480 V AC three-phase power. It is built for industrial environments that require a secure, twist-lock connection in dry, indoor locations. The device accepts #16 to #8 AWG solid or stranded copper wire via back or side screw terminals. UL 498 listed and CSA C22.2 No. 42 certified.

Sustained three-phase load performance

The receptacle carries its full 20 A rating continuously across an operating range of -40 °F to 167 °F (-40 °C to +75 °C). Brass contacts and an all-brass grounding system resist corrosion during extended duty cycles. A wire-restraint recess at each terminal reduces loosening under vibration or thermal cycling. Nylon housing maintains structural integrity at the upper temperature limit.

Thermal and installation characteristics

The nylon housing and brass components operate without active cooling in normal indoor service. Face colour coding by voltage helps prevent mating errors during installation or maintenance. Flush-mount design includes mounting hardware for standard electrical boxes. Screw terminals accept only copper wire in the specified gauge range for reliable termination.

Highlights

  • Industrial-grade locking connection with NEMA L16-20R twist-lock design
  • Reliable 20 A, 480 V AC three-phase power delivery
  • Secure wiring accepts #16 to #8 AWG copper conductors
  • Durable nylon housing with brass contacts withstands -40 °C to +75 °C
  • UL 498 listed and CSA C22.2 No. 42 certified for safety

Specifications

BrandHubbell Wiring Device-Kellems
ModelHBL2430
TypeLocking Devices
ColorBlack

Questions about this item

How much heat does the HBL2430 generate when running continuously at 20 A?

The receptacle operates continuously from -40°C to +75°C and its nylon housing with brass contacts is designed for industrial thermal loads.

What wiring and breaker must already be in place for this L16-20R receptacle?

You need a three-phase 480 V AC circuit with a 20 A breaker and #16 to #8 AWG copper wire for the screw terminals.

Will this L16-20R mate with older Hubbell twist-lock plugs on the same circuit?

Yes, the NEMA L16-20R configuration and face colour coding ensure correct mating with any compliant L16-20P plug.
