Black thermoplastic 10-50R 50 A receptacle with screw terminals

Hubbell Incorporated

Hubbell HBL7962 10-50R 50 A Receptacle

SKU CH-MAP5-J2K4G

A flush-mount, 50 A, 125/250 V AC receptacle with 10-50R configuration, screw terminals and CSA/UL certification

  • Color MappingBlack
  • TypeWiring Devices
  • Delivers 50 A continuous power with 10-50R NEMA configuration
  • Handles 125/250 V AC split-phase circuits for heavy-duty appliances
  • CSA certified and UL listed for verified safety compliance
  • Thermoplastic housing resists impact and heat in demanding environments
  • Flush-mount single-gang design fits standard electrical boxes cleanly

Hubbell HBL7962 10-50R Receptacle

The Hubbell HBL7962 is a straight-blade receptacle rated for 50 A at 125/250V AC. It uses a NEMA 10-50R configuration with three poles and three wires for single-phase power. The thermoplastic housing is black and designed for flush mounting without a cover. It suits installations needing a non-grounded, polarized outlet.

50 A capacity with screw terminals

The device carries a 50 A current rating and accepts wire connections via screw terminals on the back and side. It provides a single receptacle rated for 125/250V AC. The NEMA 1 enclosure rating and non-grounded design limit use to applications where grounding is not required. It meets CSA Certified and UL E2186 standards.

Thermoplastic housing for standard wiring

The black thermoplastic housing resists heat during normal operation at rated load. Screw-terminal connections ensure secure conductor contact without specialised tools. The flush-mount style fits standard electrical boxes for clean installation. No active cooling or moving parts are present, so noise is not a factor.

Highlights

  • Delivers 50 A continuous power with 10-50R NEMA configuration
  • Handles 125/250 V AC split-phase circuits for heavy-duty appliances
  • CSA certified and UL listed for verified safety compliance
  • Thermoplastic housing resists impact and heat in demanding environments
  • Flush-mount single-gang design fits standard electrical boxes cleanly

Specifications

BrandHUBBELL WIRING DEVICE-KELLEMS
Color MappingBlack
TypeWiring Devices

Questions about this item

Will the 10-50R receptacle accept the three-wire cord from my existing range?

Yes, the 10-50R configuration has three poles and three wires rated for 50 A at 125/250V AC, matching standard range cords of that type.

How can I verify the receptacle is wired correctly after installation?

With power off, confirm the screw terminals hold each conductor firmly; then energise the circuit and measure 125 V from each hot to neutral and 250 V between the two hots using a multimeter.

Does the package include a cover plate or mounting screws, or must I buy them separately?

The receptacle ships with no cover; a standard single-gang wall plate and mounting screws are required separately.
