Compact beige desktop firewall appliance with six PoE ports on the front panel

HPE Juniper Networking

HPE Juniper Networking SRX320 firewall appliance 6 PoE ports desktop

SKU CH-GFKD-EESX8 MPN SRX320

Desktop firewall with six PoE ports delivering 1.9 Gbps firewall and 336 Mbps VPN throughput

  • Form FactorDesktop
  • ProtocolsROUTING PROTOCOLS IPv4, IPv6, ISO, Connectionless Network Se
  • VPNTunnels: Site-to-Site, Hub and Spoke, Dynamic Endpoint, Auto
  • Power InputPower Supply: AC (external)
  • FeaturesPERFORMANCE AND SCALE Routing with packet mode (64 B packet
  • Dimensions11.81 x 1.73 x 7.52 in. (29.99 x 4.39 x 19.10 cm)
  • Consolidated security and routing in a compact desktop form factor
  • Up to 1.9 Gbps firewall throughput for branch protection
  • 336 Mbps IPSec VPN performance for secure remote access
  • Eight onboard 1 GbE ports provide integrated switching connectivity
  • 4 GB RAM and 8 GB storage support advanced threat services

Consolidated security gateway

The Juniper Networks SRX320 combines firewall, routing, switching and WAN connectivity in a single desktop appliance. It provides eight onboard Gigabit Ethernet ports, six of which supply Power over Ethernet for attached devices. The unit ships with 4 GB of system memory and 8 GB of internal storage. A compact enclosure measures 11.81 x 1.73 x 7.52 in and weighs 3.28 lb.

Small-branch deployments needing PoE

This model suits offices that require secure routing, integrated switching and PoE for phones or access points without a separate switch. It is not intended for environments that demand higher throughput than the rated 1.9 Gbps firewall or 336 Mbps IPsec VPN performance. Buyers needing rack-mount form factors or greater port density should consider other platforms.

1.9 Gbps maximum firewall throughput

The headline specification is a stateful firewall capacity of 1.9 Gbps with packet-mode processing. IPsec VPN throughput peaks at 336 Mbps, and routing performance reaches 300 Kpps at 64-byte packets. These figures define the traffic volume the appliance can inspect while maintaining security services.

Highlights

  • Consolidated security and routing in a compact desktop form factor
  • Up to 1.9 Gbps firewall throughput for branch protection
  • 336 Mbps IPSec VPN performance for secure remote access
  • Eight onboard 1 GbE ports provide integrated switching connectivity
  • 4 GB RAM and 8 GB storage support advanced threat services

Specifications

BrandJuniper Networks
SeriesSRX3000
ModelSRX320
Part NumberSRX320
Form FactorDesktop
ProtocolsROUTING PROTOCOLS
IPv4, IPv6, ISO, Connectionless Network Service (CLNS)
Static routes
RIP v1/v2
OSPF/OSPF v3
BGP with Route Reflector
IS-IS
Multicast: Internet Group Management Protocol (IGMP) v1/v2, Protocol Independent Multicast (PIM) sparse mode (SM)/dense mode (DM)/source-specific multicast (SSM), Session Description Protocol (SDP), Distance Vector Multicast Routing Protocol (DVMRP), Multicast Source Discovery Protocol (MSDP), Reverse Path Forwarding (RPF)
Encapsulation: VLAN, Point-to-Point Protocol (PPP), Frame Relay, High-Level Data Link Control (HDLC), serial, Multilink Poin
VPNTunnels: Site-to-Site, Hub and Spoke, Dynamic Endpoint, AutoVPN, ADVPN, Group VPN (IPv4/ IPv6/ Dual Stack)
Juniper Secure Connect: Remote access / SSL VPN
Configuration payload: Yes
IKE Encryption algorithms: Prime, DES-CBC, 3DES-CBC, AEC-CBC, AES-GCM, SuiteB
IKE authentication algorithms: MD5, SHA-1, SHA-128, SHA-256, SHA-384
Authentication: Pre-shared key and public key infrastructure (PKI) (X.509)
IPSec (Internet Protocol Security): Authentication Header (AH) / Encapsulating Security Payload (ESP) protocol
IPSec Authentication Algorithms: hmac-md5, hmac-sha-196, hmac-sha-256
IPSec
Power InputPower Supply: AC (external)
FeaturesPERFORMANCE AND SCALE
Routing with packet mode (64 B packet size) in Kpps: 300
Routing with packet mode (IMIX packet size) in Mbps: 800
Routing with packet mode (1,518 B packet size in Mbps: 1,500
Stateful firewall (64 B packet size) in Kpps: 200
Stateful firewall (IMIX packet size) in Mbps: 600
Stateful firewall (1,518 B packet size) in Mbps: 1,900
IPSec VPN (IMIX packet size) in Mbps: 116
IPSec VPN (1,400 B packet size) in Mbps: 336
Application visibility and control in Mbps: 500
Recommended IPS in Mbps: 200
Next-generation firewall in Mbps: 226
Secure Web Access firewall in Mbps:
Dimensions11.81 x 1.73 x 7.52 in. (29.99 x 4.39 x 19.10 cm)
Weight3.28 lb (1.51 kg)
Shipping weight3.18 kg
Package size389 × 361 × 124 mm

Questions about this item

How can I verify the SRX320 is routing traffic at line rate after installation?

Check the performance counters for 300 Kpps at 64-byte packets, 800 Mbps with IMIX traffic, or 1,500 Mbps at 1,518-byte packets to confirm expected throughput.

What ships with the SRX320 desktop unit and what must I source separately?

The box includes the SRX320 appliance with 8×1GbE ports (6 PoE), 4 GB RAM, 8 GB storage, and an external AC power supply; rack-mount brackets, transceivers, and feature licences are purchased separately.

Which SRX300-series model should I choose for up to 1.9 Gbps firewall and 336 Mbps IPsec VPN performance?

Select the SRX320; it delivers 1.9 Gbps firewall and 336 Mbps VPN throughput in a desktop form factor, whereas the SRX300 is rated for 1 Gbps firewall and 30 Mbps VPN.
