Silver desktop network switch with 24 RJ45 ports and four SFP uplink slots

HPE Juniper Networking

HPE Juniper Networking EX4100-F-24P 24-port PoE+ network switch

SKU CH-W23W-VNQ6C MPN EX4100-F-24P

Managed 24-port Gigabit PoE+ switch with 370 W budget and four 1/10 GbE uplinks

  • FormatDesktop
  • Network Management TypeManaged
  • Primary Ports24 x RJ45
  • SecurityMedia Access Control (MAC) limiting (per port and per VLAN)
  • PoEYes
  • QoSL2 QoS L3 QoS Ingress policing: 1 rate 2 color Hardware queu
  • 24 PoE+ ports power access points and IP phones with up to 30 W each
  • 370 W total PoE budget supports dense deployments without extra injectors
  • Four 1/10 GbE SFP/SFP+ uplinks plus four 10 GbE stacking ports expand bandwidth and resilience
  • Layer 3 routing with 32 650 IPv4 routes and 16 100 multicast entries handles campus traffic locally
  • Mist AI cloud management enables zero-touch provisioning and AI-driven troubleshooting from anywhere

PoE+ access for 24 devices

This managed switch provides 24 RJ45 ports that deliver up to 30W each for IP phones, cameras and access points. A total PoE budget of 370W powers the full complement of ports without oversubscription. Desktop format suits wiring closets or branch offices needing quiet, fanless operation. Layer 3 routing handles IPv4 traffic between VLANs locally.

370W budget and uplink headroom

The 370W pool comfortably runs 24 class 4 endpoints simultaneously, leaving no headroom only when every port draws maximum power. Four 1GbE/10GbE SFP/SFP+ uplinks and four dedicated 10GbE stacking ports provide aggregation bandwidth for uplink or virtual chassis growth. Jumbo frames up to 9216 bytes pass through without fragmentation.

Desktop chassis with stacking ports

The 1U desktop enclosure measures 17.36 x 1.72 x 12.26 inches and weighs 6.61 pounds, fitting standard shelves or racks with optional brackets. Front-to-rear airflow keeps the unit cool in stacked deployments. Dedicated stacking ports on the rear simplify cabling when building a virtual chassis of up to 10 members.

Highlights

  • 24 PoE+ ports power access points and IP phones with up to 30 W each
  • 370 W total PoE budget supports dense deployments without extra injectors
  • Four 1/10 GbE SFP/SFP+ uplinks plus four 10 GbE stacking ports expand bandwidth and resilience
  • Layer 3 routing with 32 650 IPv4 routes and 16 100 multicast entries handles campus traffic locally
  • Mist AI cloud management enables zero-touch provisioning and AI-driven troubleshooting from anywhere

Specifications

BrandJuniper Networks, Inc.
SeriesEX4100-F
ModelEX4100-F-24P
Part NumberEX4100-F-24P
FormatDesktop
Network Management TypeManaged
Primary Ports24 x RJ45
SecurityMedia Access Control (MAC) limiting (per port and per VLAN)
Allowed MAC addresses: 64,000
Dynamic Address Resolution Protocol (ARP) dynamic ARP inspection (DAI)
IP source guard
Local proxy ARP
Static ARP support
Dynamic Host Configuration Protocol (DHCP) snooping
Captive portal
Persistent MAC address configurations
Distributed denial of service (DDoS) protection (CPU control path flooding protection)
PoEYes
QoSL2 QoS
L3 QoS
Ingress policing: 1 rate 2 color
Hardware queues per port: 12 (8 unicast + 4 multicast)
Scheduling methods (egress): Strict priority (SP), weighted deficit round-robin (WDRR)
802.1p, DiffServ code point (DSCP)/IP precedence trust and marking
L2-L4 classification criteria: Interface, MAC address, Ethertype, 802.1p, VLAN, IP address, DSCP/IP precedence, TCP/UDP port numbers, and more
Congestion avoidance capabilities: Tail drop, weighted random early detection (WRED)
Layer3
Layer 2 FeaturesLayer 2 switching
Maximum MAC addresses per system: 64,000
Jumbo frames: 9216 bytes
Range of possible VLAN IDs: 1 to 4094
Virtual Spanning Tree (VST) instances: 253
Port-based VLAN
Voice VLAN
Physical port redundancy: Redundant trunk group (RTG)
Compatible with Per-VLAN Spanning Tree Plus (PVST+)
Routed VLAN interface (RVI)
Uplink failure detection (UFD)
ITU-T G.8032: Ethernet Ring Protection Switching IEEE 802.1AB: Link Layer Discovery Protocol (LLDP)
LLDP-MED with VoIP integration
Default VLAN and multiple VLAN range support
MAC learning deactivate
Persistent MAC learning (sticky M
Layer 3 FeaturesLayer 3 features: IPv4
Maximum number of ARP entries: 32,000
Maximum number of IPv4 unicast routes in hardware: 32,650 prefixes; 32,150 host routes
Maximum number of IPv4 multicast routes in hardware: 16,100 multicast routes
Routing protocols: RIPv1/v2, OSPF, BGP, IS-IS
Static routing
Routing policy
Bidirectional Forwarding Detection (BFD)
L3 redundancy:
Virtual Router Redundancy Protocol (VRRP)
VRF-Lite
Layer 3 features: IPv6
Maximum number of neighbor discovery (ND) entries: 16,000
Maximum number of IPv6 unicast routes in hardware: 16,200 prefixes; 16,050 host routes
Maximum number
PoE Ports24 x PoE
PoE Power Budget370W
Dimensionswith power supply installed: 17.36 x 1.72 x 12.26 in. (44.09 x 4.37 x 31.14 cm)
Weight6.61 lb (3 kg)
Shipping weight7.47 kg
Package size559 × 508 × 152 mm

Questions about this item

Will the 370W PoE+ budget still power my older 10/100/1000BASE-T devices alongside the new PoE+ endpoints?

Yes, the 24 RJ45 ports negotiate 10/100/1000 speeds automatically, so legacy endpoints work while the 370W budget feeds up to 30W per PoE+ port.

How can I confirm the switch is forwarding traffic correctly after setup?

Check the port LEDs for link/activity on each of the 24 RJ45 and four SFP/SFP+ uplinks, then verify MAC learning and VLAN tags in the Junos CLI or Mist dashboard.

What ships in the box and what must I buy separately?

The desktop chassis with installed power supply is included; SFP or SFP+ transceivers for the four 1GbE/10GbE uplink ports and stacking cables for the four dedicated 10GbE stacking ports are sold separately.
