Rectangular silver metal network switch with 48 RJ45 ports and four SFP+ slots on the front

HPE Juniper Networking

HPE Juniper Networking EX2300-48P 48-port PoE+ network switch

SKU CH-Y7HB-78YJA MPN EX2300-48P

Managed Layer 3 switch with 48 PoE+ RJ45 ports and four SFP+ uplinks for high-speed aggregation

  • Switch TypeLayer 3 Switch
  • FormatDesktop
  • Network Management TypeManaged
  • Primary Ports48 x RJ45 + 4 x SFP+
  • MAC Address Table16K
  • PoEYes
  • 48 PoE+ ports power phones and cameras directly
  • Four SFP+ uplinks give 10 GbE aggregation links
  • Layer 3 routing handles 512 IPv4 prefixes
  • Virtual Chassis merges four switches into one logical unit
  • Energy Efficient Ethernet cuts power on active 1 GbE ports

48-port PoE+ Layer 3 switch

The EX2300-48P is a managed Layer 3 switch with 48 RJ45 ports supporting 10/100/1000BASE-T and PoE+. It includes four SFP/SFP+ uplink ports for 1GbE or 10GbE connectivity. The unit is rack-mountable and designed for converged enterprise network access deployments.

Installation and common issues

The switch ships as a fixed-configuration desktop or rack-mount unit with standard mounting hardware. Optics for the four SFP/SFP+ uplinks are sold separately and must be sourced to match the desired link distance and fibre type. Virtual Chassis technology allows up to four switches to be interconnected and managed as a single logical device, simplifying initial onboarding through Juniper Mist Wired Assurance.

Capacity and headroom

The MAC address table holds 16K entries and supports jumbo frames up to 9216 bytes. Layer 3 resources include 1,500 ARP entries, 512 IPv4 unicast route prefixes and 2,048 multicast groups. The switch supports 4093 VLANs with 2044 active simultaneously. Each port provides eight hardware egress queues with strict priority and shaped deficit weighted round-robin scheduling for traffic shaping.

Highlights

  • 48 PoE+ ports power phones and cameras directly
  • Four SFP+ uplinks give 10 GbE aggregation links
  • Layer 3 routing handles 512 IPv4 prefixes
  • Virtual Chassis merges four switches into one logical unit
  • Energy Efficient Ethernet cuts power on active 1 GbE ports

Specifications

BrandJuniper Networks
SeriesEX2300
ModelEX2300-48P
Part NumberEX2300-48P
Switch TypeLayer 3 Switch
FormatDesktop
Network Management TypeManaged
Primary Ports48 x RJ45 + 4 x SFP+
MAC Address Table16K
PoEYes
QoSLayer 2 QoS
Layer 3 QoS
Ingress policing: one-rate two-color; two-rate three color markers
Hardware queues per port: 8
Scheduling methods (egress): Strict Priority (SP), shaped deficit weighted round-robin (SDWRR)
802.1p, DSCP /IP precedence trust and marking
L2-L4 classification criteria: Interface, MAC address, Ether Type, 802.1p, VLAN, IP address, DSCP/IP precedence, TCP/UDP port numbers
Congestion avoidance capabilities: Tail drop and WRED
Layer3
Layer 2 FeaturesMaximum MAC addresses in hardware: 16,000
Jumbo frames: 9216 bytes
Number of VLANs supported: 4093 (2044 active VLAN)
Range of possible VLAN IDs: 1-4094
Port-based VLAN
MAC-based VLAN
Voice VLAN
Layer 2 Protocol Tunneling (L2PT)
IEEE 802.1ak: Multiple VLAN Registration Protocol (MVRP)
Compatible with Per-VLAN Spanning Tree Plus (PVST+)
RVI (Routed VLAN Interface)
IEEE 802.1AB: Link Layer Discovery Protocol (LLDP) LLDP-MED with VoIP integration
IEEE 802.1ad Q-in-Q tunneling
IEEE 802.1br: Bridge Port Extension
IEEE 802.1D: Spanning Tree Protocol
IEEE 802.1p: CoS Prioritization
IEEE 802
Layer 3 FeaturesLayer 3 Features: IPv4
Maximum number of ARP entries: 1,500
Maximum number of IPv4 unicast routes in hardware: 512 prefixes; 4,096 host routes
Maximum number of IPv4 multicast routes in hardware: 2,048 groups; 2,048 multicast routes
Routing Protocols: RIP v1/v2, OSPF v1/v2
Static routing
Routing policy
Bidirectional Forwarding Detection (BFD) with slow timers (> 3 sec)
IP directed broadcast
Layer 3 Features: IPv6
Maximum number of Neighbor Discovery (ND) entries: 1,500
Maximum number of IPv6 unicast routes in hardware: 512 prefixes; 2,048 host routes
Maximum number of IPv6 multicast
Shipping weight20.87 kg
Package size526 × 500 × 163 mm

Questions about this item

How do I verify the EX2300-48P is forwarding at wire-rate after setup?

Check the Packet Forwarding Engine counters in the CLI or Mist dashboard; they should show line-rate throughput on all 48 RJ45 and 4 SFP+ ports with zero drops when control-plane features are enabled.

What ships with the EX2300-48P and what must I purchase separately?

The switch includes the chassis and 48 PoE+ RJ45 ports; the 4 SFP/SFP+ uplink transceivers are sold separately and must be bought to activate the 1/10GbE uplinks.

Which uplink option should I choose for the 4 SFP+ slots on the EX2300-48P?

Select 1GbE SFP modules for standard aggregation links or 10GbE SFP+ modules when higher uplink bandwidth to the core is required; both form factors fit the same four slots.
