White square ceiling-mount wireless access point with smooth matte finish and subtle branding

HPE Aruba Networking

HPE Aruba Networking AP-725 Wi-Fi 7 access point S4A25A

SKU CH-DC6D-VCXP6 MPN S4A25A

Tri-band Wi-Fi 7 indoor access point with 2.5 Gbps Ethernet, PoE power and integrated IoT radio delivering 4.7 Gbps aggregate throughput

  • WiFi GenerationWi-Fi 7
  • AntennaIntegrated down-tilt omni-directional antennas for 2x2 MIMO
  • Mounting LocationIndoor
  • Max Power ConsumptionMaximum (worst case) power consumption (without/with USB dev
  • CertificationsBluetooth SIG; Ethernet Alliance (PoE, PD device, Class 4) W
  • ComplianceFCC/ISED CE Marked RED Directive 2014/53/EU UL/IEC/EN 62368-
  • Wi-Fi 7 with multilink operation boosts throughput and cuts latency
  • Tri-band 2x2 MIMO radios deliver 4.7 Gbps aggregate data rate
  • Integrated IoT radio supports BLE and Zigbee for smart building devices
  • Powered by PoE 802.3at with 2.5 Gbps Ethernet uplink
  • AI power-save mode reduces energy use to 17.1W

Tri-band Wi-Fi 7 campus access point

The HPE Aruba AP-725 is an indoor wireless access point built for campus environments. It delivers Wi-Fi 7 across three radios covering 2.4 GHz, 5 GHz and 6 GHz bands. Integrated down-tilt omni-directional antennas provide 2x2 MIMO with peak gains of 5.1 dBi at 2.4 GHz and 5.4 dBi at both 5 GHz and 6 GHz. The unit mounts horizontally on ceilings with a roughly 30-degree downtilt for optimal coverage.

4.7 Gbps aggregate tri-band data rate

Three 2x2 MIMO radios combine for a maximum tri-band aggregate data rate of 4.7 Gbps. Wi-Fi 7 multilink operation enables channel aggregation and 4K QAM for higher throughput and lower latency. The 6 GHz band more than doubles available capacity compared with previous allocations. An integrated IoT radio supports BLE or 802.15.4/Zigbee for building automation. Maximum power draw is 17.1 W without USB devices and 22.8 W with them attached.

PoE-powered with 2.5 Gbps Ethernet uplink

The access point is powered by IEEE 802.3at PoE Class 4, eliminating the need for a local power outlet. A single 2.5 Gbps Ethernet port provides the wired uplink. AI-powered dynamic power save mode reduces energy consumption during low-traffic periods. Certifications include Wi-Fi Alliance Wi-Fi CERTIFIED for a, b, g, n, ac, 6 and 7 with WPA2, WPA3 and Enhanced Open. Compliance covers FCC/ISED, CE RED Directive 2014/53/EU and UL/IEC/EN 62368-1 safety standards.

Highlights

  • Wi-Fi 7 with multilink operation boosts throughput and cuts latency
  • Tri-band 2x2 MIMO radios deliver 4.7 Gbps aggregate data rate
  • Integrated IoT radio supports BLE and Zigbee for smart building devices
  • Powered by PoE 802.3at with 2.5 Gbps Ethernet uplink
  • AI power-save mode reduces energy use to 17.1W

Specifications

BrandHPE
Series720 Series Campus Access Points
ModelAP-725
Part NumberS4A25A
WiFi GenerationWi-Fi 7
AntennaIntegrated down-tilt omni-directional antennas for 2x2 MIMO with peak antenna gain of 5.1 dBi in 2.4 GHz, 5.4 dBi in 5 GHz, and 5.4 dBi in 6 GHz. Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees.
Mounting LocationIndoor
Max Power ConsumptionMaximum (worst case) power consumption (without/with USB devices attached): 17.1W/22.8W
CertificationsBluetooth SIG; Ethernet Alliance (PoE, PD device, Class 4) Wi-Fi Alliance (WFA):- Wi-Fi CERTIFIED a, b, g, n, ac, 6, 7- WPA2 and WPA3- Enhanced Open (OWE)- WMM, W-Fi Agile Multiband
ComplianceFCC/ISED CE Marked RED Directive 2014/53/EU UL/IEC/EN 62368-1
Shipping weight1.32 kg
Package size269 × 249 × 84 mm

Questions about this item

Will the AP-725's 2.5 Gbps Ethernet port work with my existing gigabit switch?

Yes, the 2.5 Gbps port auto-negotiates down to 1 Gbps so it connects to your current switch while still accepting PoE power.

How can I verify the AP-725 is operating correctly after ceiling mounting?

Check that the status LEDs show solid green for power and each radio, then confirm clients associate on 2.4 GHz, 5 GHz and 6 GHz with MLO enabled.

Does the S4A25A include mounting brackets or a PoE injector in the box?

The access point ships with integrated antennas only; mounting hardware and a PoE+ injector or compatible switch must be purchased separately.
