Silver 1U rack-mount switch with 48 RJ45 ports and four SFP+ cages

HPE

HPE Aruba CX 6200F 48G Class-4 PoE 4SFP+ 370W Switch JL727B#ABA

SKU CH-AZX8-GCJNN MPN JL727B#ABA

A 48-port Gigabit switch with four 10 Gigabit SFP+ uplinks and 370 W Class-4 PoE budget for powering access points and cameras

  • Primary Ports48 x RJ45 + 4 x SFP
  • PoEYes
  • Layer3
  • PoE Ports48 x PoE
  • PoE Power Budget370 W
  • Max Power Consumption76 W at 230 VAC

Model CX 6200F

Option 48-port PoE, 4-port SFP+

Struck-through versions exist but are not stocked here.

  • 48 Gigabit RJ-45 ports with Class-4 PoE on every port
  • 370 W PoE budget powers dense access-point and camera deployments
  • Four 10 Gbps SFP+ uplinks provide high-speed aggregation
  • 176 Gbps switching capacity with sub-2 µs latency
  • Quad-core ARM Cortex-A72 at 1.8 GHz, 8 GB DDR4, 16 GB eMMC

Aruba CX 6200F 48-port PoE switch

The HPE Aruba CX 6200F is a Layer 3 manageable switch with 48 RJ45 ports and four SFP+ uplinks. It delivers a 370 W PoE budget across all 48 ports for Class 4 devices. The switch runs on a quad-core ARM Cortex-A72 processor at 1.8 GHz with 8 GB DDR4 memory and 16 GB eMMC storage. Switching capacity reaches 176 Gbps with up to 130.9 Mpps throughput.

Rack space power and uplink check

Verify you have 1U of rack depth for the 44.2 cm by 32.7 cm chassis and a 230 VAC supply for the 76 W maximum draw. Confirm the four SFP+ slots match your uplink modules or direct-attach cables. Ensure the 370 W PoE budget covers the total powered-device load you plan to connect across the 48 ports.

Suits PoE-dense access layers not core routing

This switch fits access-layer deployments needing high-density PoE for phones cameras or APs with 10 Gbps uplinks. It is not for buyers who require deeper PoE budgets per port or higher core routing table capacity. Environments needing larger MAC tables or advanced data-centre features should evaluate other platforms.

Highlights

  • 48 Gigabit RJ-45 ports with Class-4 PoE on every port
  • 370 W PoE budget powers dense access-point and camera deployments
  • Four 10 Gbps SFP+ uplinks provide high-speed aggregation
  • 176 Gbps switching capacity with sub-2 µs latency
  • Quad-core ARM Cortex-A72 at 1.8 GHz, 8 GB DDR4, 16 GB eMMC

Specifications

BrandHPE
SeriesCX 2600 Series
ModelCX 2600F
Part NumberJL727B
Primary Ports48 x RJ45 + 4 x SFP
PoEYes
Layer3
PoE Ports48 x PoE
PoE Power Budget370 W
Max Power Consumption76 W at 230 VAC
Dimensions4.39 x 44.2 cm x 32.7 cm
Weight5.10 Kg
FeaturesMemory and processor
CPU: Quad Core ARM Cortex™ A72 at 1.8 GHz
Memory and Flash: 8 GB DDR4 16 GB eMMC
Latency
1 Gbps: 2.28 µSec
10 Gbps: 1.46 µSec
Throughput
Up to 130.9 Mpps
Routing/switching capacity
176 Gbps
Shipping weight6.71 kg
Package size561 × 457 × 122 mm

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What comes in the box with the JL727B#ABA and what must be purchased separately?

The switch ships with the chassis, mounting hardware and power cord; SFP+ transceivers for the four uplink slots are not included and must be bought separately.

How do I decide between the 370 W PoE budget and the 76 W system draw for my deployment?

Reserve 370 W for attached PoE devices such as phones or cameras; the switch itself draws up to 76 W at 230 VAC, so size the UPS for the combined total.

What does the 176 Gbps switching capacity mean when the switch is fully populated?

It provides 176 Gbps of non-blocking throughput across all 48 RJ45 ports and four SFP+ uplinks, with latency of 2.28 µs at 1 Gbps and 1.46 µs at 10 Gbps.
