Silver 2U rack server chassis with sixteen front drive bays and redundant power supplies

HP

HP ProLiant DL380 Gen9 2U rack server 2x Xeon E5-2630 v3 2.4GHz 32GB DDR4 2x 600GB SAS P440 4GB FBWC

SKU CH-3J5K-HRMA2

2U rack server with dual Xeon E5-2630 v3 2.4GHz CPUs, 32GB DDR4 ECC, 16 SFF bays, two 600GB 15K SAS drives, P440 4GB FBWC RAID and redundant 500W power

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610
  • Dual Xeon E5-2630 v3 CPUs deliver 16 cores at 2.4GHz for multi-threaded workloads
  • 32GB DDR4 ECC memory across 24 DIMM slots supports up to 3TB total capacity
  • Two 600GB 15K SAS drives on P440 4GB FBWC controller enable RAID 0/1/5/6/10/50/60
  • 16 SFF hot-swap bays in 2U chassis allow dense storage expansion
  • Dual 500W redundant hot-swap power supplies maintain uptime during module failure

Dual Xeon E5-2630 v3 2U rack server

The HP ProLiant DL380 Gen9 is a 2U rack server equipped with two Intel Xeon E5-2630 v3 eight-core processors running at 2.4 GHz. It ships with 32 GB of DDR4 ECC registered memory installed across 24 DIMM slots. The system includes a Smart Array P440 controller with 4 GB flash-backed write cache and two 600 GB 15 K SAS drives in a 16-bay SFF chassis. Dual 500 W hot-swap power supplies provide redundancy for continuous operation.

Check rack depth power and drive carriers

Verify that your rack can accommodate a 2U unit with redundant hot-swap power supplies and that the PDU connectors match the dual 500 W supplies. Confirm the SAS backplane supports the 16 SFF bays and that any additional drives include the required carriers. The installed memory uses DDR4 ECC registered modules up to 2400 MT/s; expansion must match this specification. No operating system is included so installation media must be prepared separately.

Expands to 24 SFF bays and 3 TB memory

The chassis supports an optional second 8-bay cage to reach 24 SFF drives while the P440 controller manages RAID 0 1 5 6 10 50 60 across all attached SAS devices. Memory can scale to 3 TB using the 24 DIMM slots when populated with compatible DDR4 registered modules. The Matrox G200eH2 graphics output provides basic management display. Redundant power supplies free up a PDU branch for other equipment in the same rack.

Highlights

  • Dual Xeon E5-2630 v3 CPUs deliver 16 cores at 2.4GHz for multi-threaded workloads
  • 32GB DDR4 ECC memory across 24 DIMM slots supports up to 3TB total capacity
  • Two 600GB 15K SAS drives on P440 4GB FBWC controller enable RAID 0/1/5/6/10/50/60
  • 16 SFF hot-swap bays in 2U chassis allow dense storage expansion
  • Dual 500W redundant hot-swap power supplies maintain uptime during module failure

Specifications

BrandHP
SeriesProLiant
ModelProliant DL380 G9
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity32GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart Array P440/4GB FBWC Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200eH2
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 3 PCIe 3.0 Slots (1-3) available: 2x Full-Height Half Length, 1x Half-Lenth Full Height. Optional 3 additional slots (Slot 2 PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the HP ProLiant DL380 Gen9 include all drive trays and rails, or must any mounting hardware be purchased separately?

The server ships with 16 SFF bays populated by two 600 GB SAS drives on trays; the remaining empty bays accept additional 2.5" SAS drives with their own trays, and rack rails are included for 2U mounting.

Which memory capacity should I choose if I want to reach the maximum supported by the installed Xeon E5-2630 v3 processors?

Each processor supports 12 DDR4 DIMM slots; with two CPUs the platform can scale to 3 TB using 64 GB modules, so start with the 32 GB fitted and add matched ECC Registered DDR4 up to 2400 MT/s as workloads grow.

What does the P440 controller's 4 GB FBWC cache mean for database performance on the two 15 K SAS drives?

The 4 GB flash-backed write cache absorbs synchronous write bursts, allowing the Smart Array P440 to acknowledge transactions at RAM speed while destaging to the dual 600 GB 15 K SAS drives in RAID 1, reducing latency for OLTP workloads.
