Silver 1U rack server with four front 3.5-inch drive bays

HP

HP ProLiant DL360 G9 1U rack server 2× E5-2670v3 12-core 2.3 GHz 8 GB DDR4 4× 1 TB SAS H240ar

SKU CH-5HTJ-AVHAT

1U rack server with dual 12-core Xeon CPUs, 8 GB DDR4, and four 1 TB SAS drives on an H240ar controller

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon E5 v3
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 8GB

HDD 4 x 1TB SAS

  • 24 total cores handle heavy workloads
  • 8 GB DDR4 memory supports ECC reliability
  • Four 1 TB SAS drives provide bulk storage
  • H240ar controller enables RAID 0/1/5/6/10/50/60
  • Dual 500 W redundant supplies keep uptime

Dense 1U dual-socket server

The HP ProLiant DL360 G9 is a 1U rack system with two Intel Xeon E5-2670v3 processors, each providing twelve cores at 2.3 GHz. It ships with 8 GB of DDR4 memory and four 1 TB 7.2K SAS drives connected to a Smart HBA H240ar controller. Redundant 500 W hot-swap power supplies are included.

Suited for thread-heavy tasks.

The dual-socket design with 24 total cores and hyper-threading suits virtualisation hosts, database nodes or batch-processing clusters that fit in a single rack unit. Buyers who need dedicated graphics acceleration or more than four internal drive bays should look at other platforms.

Four-bay LFF chassis limits internal storage

Only four 3.5-inch SAS drive bays are available, so total raw capacity is capped at the installed 4 TB unless external enclosures are added. The H240ar controller supports RAID 0, 1, 5, 6, 10, 50 and 60 across those bays.

Highlights

  • 24 total cores handle heavy workloads
  • 8 GB DDR4 memory supports ECC reliability
  • Four 1 TB SAS drives provide bulk storage
  • H240ar controller enables RAID 0/1/5/6/10/50/60
  • Dual 500 W redundant supplies keep uptime

Specifications

BrandHP
SeriesProLiant
ModelProliant DL360 G9
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon E5 v3
MAX Processors2
ChipsetIntel C610
Installed Memory Size8GB
Memory TypeDDR4
Max Memory Capacity8GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/s ECC Registered, actual memory speed dependent on the processor capability).
Number of Memory Slots24
Storage ControllerHP Smart HBA H240ar Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media DrivesNone
GPU TypeMatrox G200
Video Memory16MB
Remote ManagementiLO Management (standard).
LAN Ports4 x Ports
Expansion SlotsPrimary Riser: 2 PCIe 3.0 Slots (1 & 2) available: 1x Full-Height Half Length, 1x Half-Lenth Half Height. Optional PCIe 3.0 slot 3 - Full-Height Half Height (Secondary PCIe Riser and dual CPU required).
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight63.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install the 3.5-inch SAS drives into the 4 LFF bays, and what step is often missed?

Slide each drive into a bay until the latch clicks; the step often missed is confirming the H240ar controller detects all four drives in the BIOS before configuring RAID.

Which components will need replacement first during long-term operation?

The two 500 W redundant power supplies and the 7.2K RPM SAS drives are the primary field-replaceable units; DDR4 ECC RDIMMs and system fans are also serviceable.

What thermal or power limit appears first when both Xeon E5-2670v3 CPUs run at 2.3 GHz continuously?

The 500 W redundant power supply rating is the first hard limit; sustained full-load draw from 24 cores plus drives and memory can approach this ceiling.
