HP Poly Studio X70 video bar with TC10 touch controller, matte black finish

HP

HP Poly Studio X70 Video Bar with TC10 Controller 8L539AA#ABA

SKU CH-YS9G-E4FH7 MPN 8L539AA#ABA

All-in-one video bar with dual 20 megapixel cameras, 140° field of view, 4K UHD at 30 fps, and TC10 controller for large meeting spaces

  • ConnectivityInterfaces/Ports USB Number of Network (RJ-45) Ports: 2 Netw
  • CameraCamera Resolution: 20 Megapixel Total Number of Cameras: 2 F
  • Digital Video Capture ResolutionVideo Encoding: H.264 High Profile H.264 AVC H.265 Maximum F
  • MicrophoneAudio Encoding: G.729a G.728 G.722.1C G.722.1 G.722 G.719 G.
  • 4K UHD video at 3840 x 2160 resolution
  • Dual 20-megapixel cameras with 140° field of view
  • Poly DirectorAI automatic framing and tracking
  • NoiseBlockAI distraction-free audio technology
  • Dual RJ-45 ports with 1000 Mbps Ethernet

Large-room video bar

The HP Poly Studio X70 is an all-in-one video bar built for large meeting spaces. It combines dual cameras with a 20 megapixel resolution and a 140-degree field of view. Integrated microphones use NoiseBlockAI technology to suppress background noise. The included TC10 controller provides touch-based meeting management.

Network installation

Connect the unit to the network using one of two RJ-45 ports supporting 10/100/1000Base-T for up to 1000Mbps data transfer. A single HDMI input and two HDMI outputs handle display and content sharing connections. USB and audio line ports provide additional peripheral options. The kit is GSA and TAA compliant for government procurement.

Video and audio limits

Live and content video resolution tops out at 3840 x 2160 at 30 frames per second. Supported video encoding standards include H.264 High Profile, H.264 AVC and H.265. Audio encoding covers G.711, G.719, G.722, G.722.1, G.722.1C, G.728 and G.729a. The system follows H.235.6 ITU-T recommendations for security.

Highlights

  • 4K UHD video at 3840 x 2160 resolution
  • Dual 20-megapixel cameras with 140° field of view
  • Poly DirectorAI automatic framing and tracking
  • NoiseBlockAI distraction-free audio technology
  • Dual RJ-45 ports with 1000 Mbps Ethernet

Specifications

BrandHP
ModelPoly Studio X70
ConnectivityInterfaces/Ports
USB
Number of Network (RJ-45) Ports: 2
Network (RJ-45)
Audio Line In
Audio Line Out
Number of HDMI Inputs: 1
Number of HDMI Outputs: 2
HDMI In
HDMI Out
Number of Audio Line Out: 1
Part Number8L539AA#ABA
CameraCamera Resolution: 20 Megapixel
Total Number of Cameras: 2
Field Of View (FOV) Angle: 140°
Digital Video Capture ResolutionVideo Encoding:
H.264 High Profile
H.264 AVC
H.265
Maximum Frame Rate: 30 fps
Maximum Video Resolution (Live): 3840 x 2160
Maximum Video Resolution (Content): 3840 x 2160
Graphics Modes (Live): 4K UHD
Graphics Modes (Content): 4K UHD
MicrophoneAudio Encoding:
G.729a
G.728
G.722.1C
G.722.1
G.722
G.719
G.711
Shipping weight10.05 kg
Package size940 × 326 × 276 mm

Questions about this item

How can I confirm the Poly Studio X70 is capturing 4K UHD video at 30 fps after installation?

Check the on-screen display or management console for a 3840 x 2160 live resolution and 30 fps frame rate indicator during a test call.

What cables and accessories are included with the 8L539AA#ABA kit versus what must be sourced separately?

The kit includes the X70 video bar and TC10 controller; you must supply two RJ-45 network cables, one HDMI input cable, up to two HDMI output cables, and any audio line cables.

Which version of the Studio X70 should I choose for a large room needing dual-camera 140° coverage and GSA/TAA compliance?

This 8L539AA#ABA model provides dual 20-megapixel cameras with 140° field of view and is the GSA/TAA-compliant No Radio configuration.
