Silver rack-mount network switch 1U with 24 RJ45 ports and four SFP+ uplinks

HP

HP JL677A 6100 24G Class4 PoE 4SFP+ 370W network switch

SKU CH-DHCG-WW9NJ MPN JL677A

A 24-port Gigabit PoE switch with four 10 Gigabit SFP+ uplinks and a 370 W power budget in a 1U rack-mountable chassis

  • Switch TypeEthernet Switch
  • Dimensions17.4 in x 10.6 in x 1.7 in
  • Weight9.24 lbs
  • 24 Gigabit PoE ports power access points and cameras directly
  • 370 W PoE budget supports dense deployments without extra injectors
  • Four 10 GbE SFP+ uplinks provide high-speed aggregation
  • Layer 3 routing enables inter-VLAN traffic on the switch
  • 1U rack-mountable chassis fits standard cabinets with 17.4 in depth

Aruba 6100 24G Class4 PoE Switch

The Aruba 6100 24G Class4 PoE 4SFP+ 370W Switch is a 1U rack-mountable Ethernet switch that delivers 24 Gigabit PoE ports and four 10 Gigabit SFP+ uplink slots. It supports Layer 3 routing and provides a 370 W PoE budget from a single installed power supply. Wall-mountable brackets are also included.

Suited for PoE-heavy access layers

This switch suits networks that need to power many Class 4 devices such as wireless access points or IP cameras through a single aggregation point. It is not suited for deployments that require redundant power supplies or a higher PoE budget per port than the shared 370 W pool allows.

370 W total PoE budget

The 370 W PoE budget is the decisive specification; it determines how many high-power devices can run simultaneously across the 24 RJ-45 ports. If the planned device count exceeds this budget, a switch with a larger power allocation must be chosen.

Highlights

  • 24 Gigabit PoE ports power access points and cameras directly
  • 370 W PoE budget supports dense deployments without extra injectors
  • Four 10 GbE SFP+ uplinks provide high-speed aggregation
  • Layer 3 routing enables inter-VLAN traffic on the switch
  • 1U rack-mountable chassis fits standard cabinets with 17.4 in depth

Specifications

BrandAruba
Part NumberJL677A
Switch TypeEthernet Switch
Dimensions17.4 in x 10.6 in x 1.7 in
Weight9.24 lbs
Shipping weight4.19 kg
Package size566 × 450 × 130 mm

Questions about this item

How much rack depth does the 17.4 in wide switch need?

The unit is 10.6 in deep and fits a standard 1U rack space, so allow at least that depth plus cable clearance behind the rear panel.

Which step is often missed when sliding the 1U appliance into the rack?

Install the supplied rack-mount brackets on both sides before inserting the chassis, then secure the front screws to the rack rails.

When should the single installed power supply be replaced?

The internal supply is rated for continuous 370 W PoE budget; plan a swap if output voltage drifts or fan noise increases after years of 32.70 W typical draw.
