Compact SFP+ transceiver module with LC duplex port, matte metal housing, side bail latch, and gold edge connector

HP

HP J9150D Aruba 10G SFP+ LC SR 300m OM3 Transceiver

SKU CH-NEDP-5CBS1 MPN J9150D

Connects 10 Gigabit Ethernet over multi-mode fibre up to 300 metres using an LC duplex interface

  • 10GbE throughput for high-speed data networking
  • 300m reach over OM3 multi-mode fibre
  • LC duplex connector for standard patching
  • Hot-pluggable SFP+ form factor for easy deployment
  • Compact 0.5in depth fits dense chassis

Aruba 10G SFP+ LC SR Transceiver

This HP J9150D module adds a single 10 Gigabit Ethernet port to compatible Aruba switches and routers. It uses an LC duplex connector and multi-mode fibre to cover link distances up to 300 metres on OM3 cable. The plug-in form factor allows hot-swap installation without powering down the chassis.

Suited for OM3 multi-mode runs up to 300 m

Network teams extending 10G links inside a data centre or campus building over OM3 fibre will find the reach and connector match their cabling plant. It is not for links that require single-mode fibre, distances beyond 300 m on multi-mode, or a connector other than LC duplex.

300 m reach on OM3 multi-mode fibre

The 300-metre specification on OM3 multi-mode fibre is the decisive figure when planning patch-panel-to-switch or switch-to-switch segments. If the planned run exceeds this distance or uses single-mode cable, a different transceiver must be selected.

Highlights

  • 10GbE throughput for high-speed data networking
  • 300m reach over OM3 multi-mode fibre
  • LC duplex connector for standard patching
  • Hot-pluggable SFP+ form factor for easy deployment
  • Compact 0.5in depth fits dense chassis

Specifications

No published specifications for this item yet.

Questions about this item

Which multi-mode fibre patch cables with LC connectors do I need to connect this 10GBase-SR module?

Use OM3 multi-mode fibre patch cables with LC duplex connectors to achieve the rated 300 m reach with this 10GBase-SR transceiver.

Will this SFP+ transceiver operate in a legacy 1 GbE SFP port on an older switch?

No, this module is built for 10 Gigabit Ethernet 10GBase-SR and will not link at 1 GbE in an SFP-only port.

After inserting the module, how can I confirm the link is running at the intended 10 Gbps speed?

Check the switch port status for a 10GBase-SR link up at 10 Gbps and verify the receive optical power is within the SR specification range.
