Silver 4U rackmount server chassis with eight front hot-swap drive bays and three cooling fans

HOTCFWQ

HOTCFWQ 8-Bay 4U Hot-Swap Server Chassis 6G SAS Backplane 2 GPU E-ATX

SKU CH-B5H9-BQGE4

A 4U rackmount chassis holding eight hot-swap 3.5" SAS/SATA drives with a 6Gb/s backplane, dual GPU support and three 12038 ball-bearing fans

  • Chassis TypeRackmount
  • Eight hot-swap bays for high-density storage
  • 6 Gb/s SAS backplane with temperature monitoring
  • Supports two full-height GPU cards
  • Three 12038 ball-bearing fans for airflow
  • Fits E-ATX boards up to 12" x 13

8-Bay 4U Rackmount Chassis

The HOTCFWQ server chassis fits a standard 19 inch rack and provides eight hot-swappable 3.5 inch drive bays. It supports E-ATX motherboards up to 12 by 13 inches and includes seven full-height PCIe slots for add-in cards. Two GPU graphics cards can be installed for compute workloads. The unit ships without a power supply.

Zinc-Coated Steel Build With Dual Backplane Options

The 1.0 mm SGCC zinc-coated steel frame meets EMC design standards to reduce electromagnetic interference. Buyers choose between a 6Gb/s or 12Gb/s MINI SAS backplane, each fitted with a temperature control chipset. Three 12038H ball-bearing fans provide front-to-rear airflow. The chassis accepts a standard PS2 or redundant power supply.

Front USB And Comprehensive System LEDs

Two front-accessible USB 2.0 ports are included, with an optional USB 3.0 upgrade. The control panel offers power and reset switches plus LEDs for power, drive activity, dual NIC status, unit identification, overheat or fan failure, and power supply failure. These indicators simplify daily monitoring in cloud storage, big data or security monitoring deployments.

Highlights

  • Eight hot-swap bays for high-density storage
  • 6 Gb/s SAS backplane with temperature monitoring
  • Supports two full-height GPU cards
  • Three 12038 ball-bearing fans for airflow
  • Fits E-ATX boards up to 12" x 13

Specifications

Chassis TypeRackmount

Questions about this item

What speed does the 6Gb/s MINI SAS backplane cap each drive at?

The backplane limits each drive to 6Gb/s, matching SATA III and SAS 6Gb/s maximum throughput.

What are the exact dimensions and rack standard for mounting this 4U chassis?

It measures 437.5 mm wide, 650 mm deep, 176.5 mm high and fits a standard 19" rack.

How are the three 12038H ball bearing fans installed, and what step is often missed?

The fans mount in the front fan wall; the step often missed is connecting each fan header to the motherboard or fan controller so the temperature control chipset can regulate speed.
