Silver 19-inch 2U rackmount chassis with twelve 3.5-inch hot-swap drive bays

HOTCFWQ

HOTCFWQ 2U 12-bay 6Gb SAS/SATA rackmount server chassis

SKU CH-K327-NYBV2

A 19-inch 2U rackmount chassis holding twelve hot-swap 3.5-inch SAS or SATA drives with a 6Gb/s backplane, seven full-height expansion slots and support for motherboards up to 10.5 inches deep

  • Chassis TypeRackmount
  • 12 hot-swap 3.5" bays support 6Gb/s SAS and SATA drives
  • Standard 19" rackmount fits 2U space at 88mm height
  • Seven full-height PCI/PCIe slots provide expansion capacity
  • 0mm SGCC zinc-coated steel chassis meets EMC design standards
  • Front panel includes two USB 2.0 ports and status LEDs

12-bay 2U rackmount server chassis

The HOTCFWQ chassis fits a standard 19" rack at 88 mm height and holds twelve 3.5" hot-swap drive bays. A 6Gb/s SAS/SATA backplane with a temperature-control chipset handles the drives. The steel frame uses 1.0 mm SGCC zinc-coated material and includes three 8038 ball-bearing fans as standard.

Suits storage servers needing dense 3.5" capacity

This unit targets cloud storage, big data or security monitoring builds that want twelve front-accessible bays in 2U. It supports motherboards up to 12" x 10.5" and seven full-height PCI/PCIE slots. Buyers who need 2.5" drive trays, 12Gb/s SAS backplanes or more than seven expansion slots should consider other designs.

6Gb/s SAS/SATA hot-swap backplane

The backplane sets the maximum drive interface speed at 6Gb/s for both SAS and SATA drives. Twelve bays connect through this single backplane, so every drive shares that bandwidth ceiling. If the deployment requires 12Gb/s SAS throughput per drive, this chassis will not meet that requirement.

Highlights

  • 12 hot-swap 3.5" bays support 6Gb/s SAS and SATA drives
  • Standard 19" rackmount fits 2U space at 88mm height
  • Seven full-height PCI/PCIe slots provide expansion capacity
  • 0mm SGCC zinc-coated steel chassis meets EMC design standards
  • Front panel includes two USB 2.0 ports and status LEDs

Specifications

Chassis TypeRackmount

Questions about this item

How loud and hot does the chassis get with the three included 8038 ball-bearing fans running continuously?

The chassis ships with three 8038 ball-bearing fans and has a fourth 8 cm fan position available; the backplane includes a temperature-control chipset to manage airflow.

Which motherboard form factors fit the 12" x 10.5" maximum size and the 7 full-height PCI/PCIe slots?

The chassis supports any motherboard up to 12" x 10.5" and provides seven full-height PCI/PCIe expansion slots for add-in cards.

Will my existing 6 Gb/s SAS or SATA 3.5" drives work in the 12 hot-swap bays without adapters?

Yes, the 12 hot-swap bays accept 3.5" SAS (II or III) and SATA (II or III) drives at 6 Gb/s directly on the 6 Gb/s backplane.
