Blue Holland Electronics DPD2 diplexer splitter, compact metal housing with threaded F connectors

Holland Electronics

Holland Electronics DPD2 Diplexer Splitter Blue 5-2150 MHz 28 V DC Pass

SKU CH-N5N4-CT6H6

Combines satellite and TV signals on one cable with 28 V DC pass through the SAT port across 5-2150 MHz

  • ColorBlue
  • Weight0.25
  • Combines satellite and TV signals over one cable using 5-2150 MHz bandwidth
  • Passes 28 V DC power through SAT port up to 2 A maximum
  • Solder-back sealed housing delivers 140 dB RFI shielding for clean reception
  • Compatible with Dish Network dual-tuner receivers 222, 322, 522, 622, 625, 722, 942
  • Precision F-ports and diode-protected circuitry ensure reliable indoor or outdoor installation

Holland DPD2 diplexer for satellite

The Holland Electronics DPD2 diplexer combines a satellite feed and a TV2 output onto a single coaxial run for Dish Pro and Dish Pro Plus systems. It passes 28 V DC at up to 2 A through the SAT port and operates from 5 MHz to 2150 MHz. The blue housing identifies the unit in residential or commercial installations.

Quick F-type installation with EMI shielding

The splitter uses precision-machined threaded F ports and a solder-back sealed PCB that provides 140 dB RFI shielding. Diode-protected circuitry passes DC power from any output to the input without extra wiring. No second cable is required, so installers can reuse existing wiring and finish the job quickly.

Covers 5–2150 MHz with 2 A DC headroom

The VHF/UHF/cable port handles 5–890 MHz while the SAT port covers 950–2150 MHz, supporting dual-tuner receivers such as models 222, 322, 522, 622, 625, 722 and 942. The 2 A current limit on the SAT port defines the maximum power draw; systems needing more than 2 A or frequencies outside the stated bands will require a different solution.

Highlights

  • Combines satellite and TV signals over one cable using 5-2150 MHz bandwidth
  • Passes 28 V DC power through SAT port up to 2 A maximum
  • Solder-back sealed housing delivers 140 dB RFI shielding for clean reception
  • Compatible with Dish Network dual-tuner receivers 222, 322, 522, 622, 625, 722, 942
  • Precision F-ports and diode-protected circuitry ensure reliable indoor or outdoor installation

Specifications

BrandHolland Electronics
ModelHollandDiplexerDPD2
ColorBlue
Weight0.25

Questions about this item

How can I confirm the diplexer is passing the 28 V DC supply correctly after installation?

Measure 28 V DC on the SAT port with a multimeter; the port supports up to 2 A for powering LNBs or switches.

What comes in the box and are any extra cables or connectors required?

The DPD2 diplexer splitter is supplied alone; you will need coaxial cables with F-type plugs for the SAT, VHF/UHF and combined ports.

Which version should I choose for a Dish Pro Plus system with a 722 receiver?

The DPD2 covers 950-2150 MHz on the SAT port and 5-890 MHz on the VHF/UHF port, matching the 722 and other listed dual-tuner receivers.
