Gray galvanized steel electrical box, cube-shaped, screw-on solid cover, captive screws visible, mounting holes on back

HOFFMAN

HOFFMAN ASG6X6X6 Captive Screws Electrical Box 6 in H 6 in D 6

SKU CH-H6G7-MW59V

A 6-inch carbon-steel electrical enclosure with captive-screw solid cover, galvanized finish and wall-mounting holes

  • TypeElectrical Enclosures, Wireways & Covers
  • NEMA Type 1 rating suits indoor installations
  • Galvanized carbon steel resists corrosion in dry environments
  • Captive screw cover prevents lost hardware during maintenance
  • cUL listed to CSA C22.2 No 40 and UL 50/50E
  • 12/14/16 gauge steel provides rigid wall-mount strength

Compact Steel Enclosure

The HOFFMAN ASG6X6X6 is a six-inch cubic electrical box built from carbon steel with a galvanized grey finish. It carries a NEMA Type 1 and IP30 rating, making it suitable for indoor wall-mounted installations where basic protection against solid objects and contact is required. The screw-on solid cover uses captive screws so hardware cannot be lost during maintenance. Mounting holes are integrated for direct surface attachment.

Indoor Protection Limits

The NEMA Type 1 and IP30 ratings mean the enclosure guards against accidental contact and falling debris but does not resist water jets, oil, or corrosive atmospheres. Outdoor use, wash-down areas, or hazardous locations will exceed the certified protection level. The screw-latch closure provides a secure seal only when all captive screws are fully tightened to the manufacturer's specification. Carbon steel construction requires the galvanized finish to remain intact to prevent corrosion over time.

Upgrade From Open Wiring

This enclosure replaces exposed junction boxes or non-rated cabinets where code now demands a listed metallic box with a secured cover. The jump is worth it when an inspector requires UL 50 and 50E compliance with a cUL listing per CSA C 22.2 No 40. It is not for installers needing a larger wiring volume, a transparent cover for visual inspection, or a hinged door for frequent access without tools.

Highlights

  • NEMA Type 1 rating suits indoor installations
  • Galvanized carbon steel resists corrosion in dry environments
  • Captive screw cover prevents lost hardware during maintenance
  • cUL listed to CSA C22.2 No 40 and UL 50/50E
  • 12/14/16 gauge steel provides rigid wall-mount strength

Specifications

BrandNVENT HOFFMAN
TypeElectrical Enclosures, Wireways & Covers

Questions about this item

Which enclosure size should I choose for this Hoffman model?

This unit is a single 6 in by 6 in by 6 in enclosure, so there are no alternative sizes to select.

What does the NEMA Type 1 rating mean when the box is installed?

It provides indoor protection against contact with live parts and falling dirt, but not against water or oil.

What standards cap the enclosure's protection level in practice?

It meets UL 50, 50E, CSA C22.2 No 40 and IEC 60529 IP30, limiting it to indoor, non‑hazardous locations.
