Gray powder-coated carbon steel electrical enclosure, 10 by 10 by 6 inches, screw-on solid cover with captive screws, wall-mount holes

HOFFMAN

HOFFMAN ASE10X10X6 Captive Screws Electrical Box 10 in H 6 in D

SKU CH-7ZHN-Q3A3W

Wall-mount carbon-steel enclosure, 10 × 10 × 6 in, NEMA 1 / IP30 rated with captive-screw solid cover and powder-coated grey finish

  • TypeElectrical Enclosures, Wireways & Covers
  • NEMA Type 1 rated for indoor protection
  • Carbon steel construction with powder-coated gray finish
  • Captive screw latch secures cover without loose hardware
  • cUL listed per CSA C22.2 No 40 and UL 50/50E standards
  • 10 in height, 10 in width, 6 in depth with mounting holes

Electrical enclosure for indoor wiring

The HOFFMAN ASE10X10X6 is a carbon steel electrical enclosure rated NEMA Type 1 and IP30 for indoor use. It measures 10 in height by 10 in width by 6 in depth and carries cUL listing per CSA C 22.2 No 40 and UL 50, 50E standards. The powder coated gray finish resists corrosion in dry environments. It suits electricians and facility managers mounting junction boxes or control equipment on walls.

Verify mounting surface and cable entry needs

Confirm the wall can support the 12/14/16 gauge steel box and that the mounting holes align with your stud or anchor pattern. The solid cover uses captive screws for closure so no separate fasteners are lost during maintenance. Ensure conduit or cable entries match the knockouts you will punch since the enclosure ships without pre cut openings. The IP30 rating means it is not suited for wet or dusty locations.

Powder coated steel with captive screw cover

The carbon steel body is powder coated gray for durability and the cover latches with captive screws that stay attached when opened. Mounting holes are integral to the back for direct wall attachment. The solid cover provides a clean barrier against accidental contact with live parts. The 6 in depth accommodates terminal blocks, relays or small DIN rail assemblies while keeping the profile shallow.

Highlights

  • NEMA Type 1 rated for indoor protection
  • Carbon steel construction with powder-coated gray finish
  • Captive screw latch secures cover without loose hardware
  • cUL listed per CSA C22.2 No 40 and UL 50/50E standards
  • 10 in height, 10 in width, 6 in depth with mounting holes

Specifications

BrandNVENT HOFFMAN
TypeElectrical Enclosures, Wireways & Covers

Questions about this item

What comes with the enclosure and what must be purchased separately?

The carbon-steel enclosure with powder-coated gray finish, screw-on solid cover, captive screws, and mounting holes is supplied; internal panels, DIN rails, cable glands or other accessories are not included.

Which size and gauge combination should I select for a 10-inch wall-mount application?

This model is 10 inches high, 10 inches wide and 6 inches deep with 12/14/16 gauge construction, matching the stated wall-mount dimensions.

What does the NEMA Type 1 and IP30 rating mean for everyday indoor use?

The enclosure provides basic protection against contact with live parts and falling dirt in dry indoor locations, but is not rated for water or dust ingress.
