Gray powder-coated steel electrical enclosure with screw-on cover and captive screws, 10 by 10 by 4 inches

HOFFMAN

HOFFMAN A1010SC Electrical Box 10x10x4 in IP65 NEMA 12 13

SKU CH-VDF7-9CF7H

Wall-mount steel enclosure rated IP65 and NEMA 12, 13 with captive screw cover, welded panel nuts and neoprene gasket

  • TypeElectrical Enclosures, Wireways & Covers
  • NEMA 12 and 13 ratings protect against dust and water ingress
  • IP65 rating confirms sealed performance in wet environments
  • 14/16 gauge steel construction with powder-coated gray finish resists corrosion
  • Captive screw latches and neoprene gasket maintain enclosure integrity
  • Weld nuts included for secure mounting of panels and terminals

HOFFMAN A1010SC Steel Enclosure

The HOFFMAN A1010SC is a wall-mountable steel enclosure rated NEMA 12 and 13 with an IP65 rating. It features a solid cover secured by captive screws and a neoprene gasket for a reliable seal. The powder-coated gray finish provides corrosion resistance in industrial settings. Weld nuts allow direct mounting of panels and terminals inside the box.

Suited for indoor industrial wiring

This enclosure suits installers who need a screw-fastened, gasketed steel box for wall-mounted electrical controls. It is not for applications requiring a hinged or quick-release cover. Buyers who need a larger interior volume or a transparent cover should look at something else. The 14/16 gauge steel construction is not intended for severe impact or hazardous locations.

10x10x4 inch interior with 32FR70 panel support

The 10 inch height and width with 4 inch depth gives room for terminal strips, relays or small PLC modules. The included 32FR70 interior panel provides a mounting surface for DIN rail or component layouts. Capacity runs out when wiring density demands deeper enclosures or more panel space. The Series A51SC design supports standard industrial panel builds.

Highlights

  • NEMA 12 and 13 ratings protect against dust and water ingress
  • IP65 rating confirms sealed performance in wet environments
  • 14/16 gauge steel construction with powder-coated gray finish resists corrosion
  • Captive screw latches and neoprene gasket maintain enclosure integrity
  • Weld nuts included for secure mounting of panels and terminals

Specifications

BrandNVENT HOFFMAN
TypeElectrical Enclosures, Wireways & Covers

Questions about this item

What mounting hardware do I need to install the 10x10x4 inch steel enclosure on a wall?

The box has weld nuts for a mounting panel and terminals; you supply the panel, screws and wall anchors suited to your wall material.

Can I keep my existing 14 or 16 gauge steel panels when switching to this NEMA 12 13 IP65 box?

Yes, the enclosure is built from 14/16 ga steel and includes weld nuts that accept standard panels of the same gauge.

How do I verify the IP65 seal is effective after I close the screw-on cover?

Tighten the captive screws until the neoprene gasket compresses evenly; a uniform gap and firm resistance indicate the seal is engaged.
