Gray powder-coated carbon steel electrical enclosure, 10 inches high, 6 inches deep, hinged solid cover with clamps

HOFFMAN

HOFFMAN A10106CH Electrical Box 10 in H 6 in D

SKU CH-6BN6-ES48C

Wall-mount carbon-steel enclosure with hinged solid cover, clamp closure, IP65 and NEMA 12/13 ratings

  • TypeElectrical Enclosures, Wireways & Covers
  • NEMA 12 and 13 rated for indoor dust and oil protection
  • IP65 rating resists water jets and solid ingress
  • 14/16 gauge carbon steel with powder coat finish
  • Hinged cover with screw-down clamps and neoprene gasket
  • Weld nuts accept 32FR70 interior panel for easy mounting

Industrial Enclosure 10 in Height

The NVENT HOFFMAN A10106CH is a carbon-steel electrical enclosure built for wall-mounted installations. It carries NEMA 12 and 13 ratings plus an IP65 rating, so it resists dust, dripping water and oil in industrial environments. The 10 in height and 6 in depth suit compact control panels and junction wiring.

Powder-Coated Finish With Neoprene Gasket

A gray powder-coated exterior protects the 14/16 ga steel from corrosion while the neoprene gasket seals the hinged cover against contaminants. Clamp closures secure the solid cover without tools, and welded nuts accept a 32FR70 interior panel for mounting terminals or DIN-rail gear. The enclosure ships new and ready for field wiring.

Single-Door Clamp-Latch Design

The hinged single-door layout with external clamps allows quick access for inspection or maintenance while maintaining the rated seal. Buyers who need a larger footprint, a windowed cover or a different latch style will need another model.

Highlights

  • NEMA 12 and 13 rated for indoor dust and oil protection
  • IP65 rating resists water jets and solid ingress
  • 14/16 gauge carbon steel with powder coat finish
  • Hinged cover with screw-down clamps and neoprene gasket
  • Weld nuts accept 32FR70 interior panel for easy mounting

Specifications

BrandNVENT HOFFMAN
TypeElectrical Enclosures, Wireways & Covers

Questions about this item

How do I mount the enclosure and where do installers commonly make mistakes?

Use the weld nuts on the back to secure the panel and terminals; the common error is overtightening the clamps and compressing the neoprene gasket unevenly.

What maintenance will the enclosure need over time?

Inspect the neoprene gasket periodically for compression set or cracking and replace it if the IP65 seal degrades; the powder-coated carbon steel finish requires only occasional cleaning.

What is the first limit reached under continuous outdoor exposure?

The NEMA 12/13 and IP65 ratings protect against dust and water jets, but the carbon steel body will eventually show corrosion if the powder coating is damaged.
