Stainless steel short-path distillation unit with jacketed evaporator, internal condenser, feed pump and collection flasks

HNZXIB

HNZXIB KMD-080 Short-Path Distillation Kit 0.1 m² 80 mm 220V

SKU CH-1GTH-4P0WP MPN KMD-080

path molecular distillation kit with 0.1 m² evaporation area, 80 mm barrel, 1.5 L feed funnel and 220 V operation up to 200 °C

  • TypeShort-Path Distillation
  • Voltage220V
  • 1 m² evaporation area enables high-efficiency molecular distillation
  • 80 mm barrel diameter supports continuous feed rates of 500 to 750 g/h
  • 120 W motor with 0 to 500 rpm speed control provides precise operation
  • Dual 1 L receiving flasks allow simultaneous distillate and residue collection
  • Turnkey stainless steel configuration includes jacketed vessels, feed pump and multifunction condenser

Path Distillation Kit 0.1 m²

The HNZXIB KMD-080 is a short-path distillation kit with an effective evaporation area of 0.1 m² and a barrel diameter of 80 mm. It operates on 220V power and includes a jacketed evaporator with internal condenser, external condenser, feed pump, and dual collection pumps for continuous operation. The system uses molecular free-path separation rather than boiling-point difference.

For High-Purity Plant Oil Extraction

This kit suits laboratories and pilot-scale facilities that need to extract high-purity plant oils using molecular distillation. The 1.5 L feeding funnel and feed rate of 500 to 750 g/h support continuous processing. Buyers who need larger evaporation areas or higher throughput should look at other equipment.

Evaporation Area 0.1 m² Decides Fit

The decisive specification is the effective evaporation area of 0.1 m², which determines the maximum batch capacity and throughput. With a motor speed range of 0 to 500 rpm and motor power of 120 W, the unit can operate at temperatures up to 200 °C. Match this area to your required feed volume before purchasing.

Highlights

  • 1 m² evaporation area enables high-efficiency molecular distillation
  • 80 mm barrel diameter supports continuous feed rates of 500 to 750 g/h
  • 120 W motor with 0 to 500 rpm speed control provides precise operation
  • Dual 1 L receiving flasks allow simultaneous distillate and residue collection
  • Turnkey stainless steel configuration includes jacketed vessels, feed pump and multifunction condenser

Specifications

TypeShort-Path Distillation
Voltage220V

Questions about this item

Will the 80 mm barrel diameter fit my existing 220 V heating mantle?

The evaporator barrel is 80 mm in diameter and the unit runs on 220 V, so it will match a mantle built for that size and voltage.

How can I confirm the 0.1 m² evaporation area is performing correctly once installed?

Watch for a steady feed rate between 500 and 750 g/h and a motor speed up to 500 rpm; consistent distillate flow into the 1 L receiver shows the area is working.

Does the kit include the feed pump and collection pumps, or must I order them separately?

The turnkey configuration lists a jacketed feeding vessel, feed pump, motor with mechanical sealing, jacketed evaporator, external condenser, multifunction condenser, and both distillate and residue collection pumps.
