HES
HES 4500 Series Mortise Strike
A mortise strike for fire-rated frames with a low-profile design and dual faceplates
- UL 10C fire-rated frame compatibility for code-compliant installations
- Low 1 3/8 depth profile fits tight mortise cavities
- Heavy-duty cast stainless steel construction resists forced entry
- Unique keeper pin locking design exceeds frame and hardware ratings
- Two included faceplates simplify fitment with cylindrical or mortise locksets
HES 4500 Series Mortise Strike
The HES 4500 series mortise strike is an electric strike designed for installation in UL 10C fire-rated frames with half-inch drywall penetration. It suits access-control projects that require a heavy-duty cast stainless steel keeper pin locking design. The unit includes two faceplates to accommodate a variety of cylindrical and mortise locksets up to a three-quarter throw.
Low-Profile 1 3/8 Depth Installation
The strike features a low-profile depth of 1 3/8 inches for simpler mounting in compatible frames. Its unique keeper pin locking design provides strength exceeding the ratings of the frame, door and locking hardware. Installers should verify frame preparation matches the strike dimensions and ensure proper alignment of the keeper pin to avoid binding or latch interference during operation.
Verify Frame Rating and Lockset Throw
Before ordering, confirm the frame carries a UL 10C fire rating and allows half-inch drywall penetration as required by the 4500 series design. Check that the existing lockset is a cylindrical or mortise type with a maximum throw of three-quarters of an inch. Ensure the faceplate options supplied match the specific lockset profile being used.
Highlights
- UL 10C fire-rated frame compatibility for code-compliant installations
- Low 1 3/8 depth profile fits tight mortise cavities
- Heavy-duty cast stainless steel construction resists forced entry
- Unique keeper pin locking design exceeds frame and hardware ratings
- Two included faceplates simplify fitment with cylindrical or mortise locksets
Specifications
| Brand | HES |
|---|---|
| Model | 740090010458 |
Questions about this item
How do I verify the 4500 series strike is working after installation?
Apply power and confirm the keeper pin releases smoothly when energised; the latch should engage fully without binding, indicating the unique locking design is functioning.
What comes with the 740090010458 strike and what must I source separately?
The mortise strike ships complete with two faceplates for cylindrical and mortise locksets up to 3/4 throw; you must supply the lockset, wiring and a compatible power supply.
Which version of the 4500 series strike should I choose for a fire-rated frame?
The 740090010458 model is built for UL 10C fire-rated frames with 1/2 drywall penetration and a low-profile 1 3/8 depth, matching those exact requirements.
