White CPVC inline check valve with dual socket ends

HAYWARD POOL PRODUCTS INC

HAYWARD POOL PRODUCTS INC TC2300SE 3 in Socket CPVC Check Valve

SKU CH-5SKJ-A881P MPN TC2300SE

A 3-inch CPVC inline check valve with socket connections, 3.0 psi cracking pressure and EPDM seals rated for 150 psi at 70 Degrees F

  • TypeDrain Components
  • MaterialHAWA
  • Prevents backflow with a 3.0 psi cracking pressure
  • Handles up to 150 gpm for high-volume systems
  • CPVC body resists corrosion in pool environments
  • EPDM seals operate from 40 to 190 degrees F
  • Rated for 150 psi at 70 degrees F

3 in CPVC Check Valve for Pool Plumbing

The Hayward TC2300SE is a true-union inline check valve built from CPVC with EPDM seals. It installs in a vertical orientation on 3 inch socket connections and handles flow up to 150 gpm with a 3.0 psi cracking pressure. The body is rated for water pressure of 150 psi at 70 Degrees F and temperatures between 40 and 190 Degrees F. It is supplied new for pool and spa drain lines.

Suits vertical lines needing full flow

This valve suits installers who need a full-flow inline check valve with true-union socket ends for vertical mounting. It is not for horizontal runs, steam service or systems that exceed the 150 psi water-pressure rating at 70 Degrees F. Buyers needing a different connection style, seal material or pressure class should look at other models.

3.0 psi cracking pressure sets opening point

The 3.0 psi cracking pressure determines when the valve opens, making it the key specification for matching pump head and system head loss. Confirm that this pressure fits the hydraulic design before purchase.

Highlights

  • Prevents backflow with a 3.0 psi cracking pressure
  • Handles up to 150 gpm for high-volume systems
  • CPVC body resists corrosion in pool environments
  • EPDM seals operate from 40 to 190 degrees F
  • Rated for 150 psi at 70 degrees F

Specifications

TypeDrain Components
MaterialHAWA
BrandHayward
ModelTC2300SE

Questions about this item

Should I pick the 3.0 psi cracking-pressure version or a different spring?

This model opens at 3.0 psi cracking pressure; choose it when you need that exact back-pressure threshold, otherwise select a valve with a different spring rating.

What does the 150 gpm flow rating mean once the valve is plumbed in?

At full open the valve passes 150 gpm with a full-flow design, so pipe friction and pump curve will determine the actual system flow.

The socket-by-socket CPVC connections — what pressure limit do they impose?

The CPVC body is rated for 150 psi at 70 °F water; above that temperature the allowable pressure drops per CPVC piping standards.
