White CPVC inline check valve with FNPT and socket ends

HAYWARD POOL PRODUCTS INC

HAYWARD POOL PRODUCTS INC TC20150STE 1-1/2" FNPT Socket CPVC Check Valve

SKU CH-V5QX-YZR7H MPN TC20150STE

A CPVC inline check valve with true-union FNPT and socket connections, rated for 40 gpm flow at 235 psi and 190 °F maximum temperature

  • TypeDrain Components
  • MaterialHAWA
  • Prevents backflow with 3 psi cracking pressure
  • CPVC body handles 190 Degrees F max temperature
  • True union design allows easy inline installation
  • EPDM seals rated for 235 psi at 70 Degrees F
  • Delivers 40 gpm full flow capacity

1-1/2" CPVC Check Valve for Pool Systems

This inline true union check valve uses a CPVC body with EPDM seals to handle pool water up to 190 degrees F. It accepts a 1-1/2 inch FNPT socket connection and is rated for 235 psi at 70 degrees F.

Simple true union installation

The true union design lets you thread the FNPT end and solvent-weld the socket end without special tools. Mounting must be vertical; horizontal runs will prevent the disc from seating and cause backflow.

40 gpm full-flow capacity

The valve opens at 3 psi and passes 40 gallons per minute without restriction. Systems that demand higher flow rates or operate above 235 psi will exceed the valve's rated limits.

Highlights

  • Prevents backflow with 3 psi cracking pressure
  • CPVC body handles 190 Degrees F max temperature
  • True union design allows easy inline installation
  • EPDM seals rated for 235 psi at 70 Degrees F
  • Delivers 40 gpm full flow capacity

Specifications

TypeDrain Components
MaterialHAWA
BrandHayward
ModelTC20150STE

Questions about this item

How do I confirm the check valve is operating correctly after installation?

Verify flow moves in one direction only and that the valve opens when system pressure exceeds 3 psi cracking pressure.

What comes with the TC20150STE and what must I supply?

The valve body with EPDM seals is included; you must provide 1-1/2 in pipe, solvent cement for the socket end, and thread sealant for the FNPT end.

Which version should I choose for a 1-1/2 in CPVC line rated to 235 psi at 70 Degrees F?

Select the TC20150STE model with FNPT x Socket connections, CPVC body, EPDM seals, and 40 gpm full-flow capacity.
