White PVC inline check valve with FNPT socket connections

HAYWARD POOL PRODUCTS INC

HAYWARD POOL PRODUCTS INC TC10075ST 3/4" FNPT Socket PVC Check Valve Trap

SKU CH-1293-0QZ7Q MPN TC10075ST

A 3/4-inch FNPT socket PVC check valve with Viton seals, rated for 10 gpm flow and 235 psi at 70 Degrees F

  • TypeDrain Components
  • MaterialHAWA
  • Prevents backflow with inline true union check valve
  • Handles 10 gpm full flow through 3/4 inch FNPT socket connections
  • Viton seals withstand 40 to 140 degrees F operating range
  • Rated for 235 psi maximum water pressure at 70 degrees F
  • Vertical mounting orientation ensures reliable automatic operation

Pool Check Valve with True Union Connections

This Hayward check valve uses a single-flow inline design with true union connections. The 3/4 inch FNPT by socket layout allows direct integration into PVC plumbing runs. Viton seals and seat material handle water temperatures from 40 to 140 degrees Fahrenheit. Rated for 235 psi at 70 degrees Fahrenheit with a 3 psi cracking pressure and 10 gpm full flow capacity.

PVC Body and Viton Seals for Chemical Resistance

The PVC body resists corrosion from pool chemicals and saltwater environments. Viton seals maintain elasticity across the rated temperature range. True union connections enable removal without cutting pipe, simplifying seasonal maintenance or valve replacement. Vertical mounting orientation ensures the internal mechanism seats properly under gravity and flow conditions.

Verify Pipe Size and Vertical Installation Space

Confirm the existing plumbing uses 3/4 inch pipe with compatible FNPT and socket fittings. The valve must be installed vertically to function correctly. Ensure system pressure does not exceed 235 psi at 70 degrees Fahrenheit. Steam service is not rated. Check that 10 gpm flow capacity matches the circulation pump output.

Highlights

  • Prevents backflow with inline true union check valve
  • Handles 10 gpm full flow through 3/4 inch FNPT socket connections
  • Viton seals withstand 40 to 140 degrees F operating range
  • Rated for 235 psi maximum water pressure at 70 degrees F
  • Vertical mounting orientation ensures reliable automatic operation

Specifications

TypeDrain Components
MaterialHAWA
BrandHayward
ModelTC10075ST

Questions about this item

What does the 3/4" FNPT x Socket connection mean for pipe compatibility?

The valve accepts a 3/4 inch female NPT thread on one end and a solvent-weld socket on the other, allowing direct connection to schedule 40 PVC pipe.

What clearance does the true-union body need for removal?

The inline true-union design requires enough axial space to unscrew both union nuts so the body can be lifted out for cleaning.

How is the Viton seat oriented during installation?

Install the valve vertically with flow entering the socket end so the internal check mechanism seats against the Viton seal at 3 psi cracking pressure.
