White PVC butterfly valve with lever handle and wafer body

HAYWARD POOL PRODUCTS INC

HAYWARD POOL PRODUCTS INC BYCS1060E1LGA Butterfly Valve trap

SKU CH-M6PN-9XTRP MPN BYCS1060E1LGA

A 6-inch PVC butterfly valve with lever handle rated for 150 psi water pressure and a 40 to 140 degree Fahrenheit temperature range

  • TypeDrain Components
  • MaterialHAWA
  • Handles high pressure with 150 psi rating
  • Operates reliably from 40 to 140 Degrees F
  • Quick manual control via lever handle
  • Durable PVC body with EPDM liner
  • Meets ISO 5211 mounting standard

6-Inch PVC Butterfly Valve

This Hayward butterfly valve is a wafer-style drain component built from PVC with an EPDM liner and a PVC disc. It fits a 6-inch pipe and uses a lever handle for manual operation. The valve is rated for a maximum water pressure of 150 psi and a temperature range of 40 to 140 degrees Fahrenheit. It conforms to ISO 5211 mounting standards.

Pool and industrial water systems

The valve suits installations that require a corrosion-resistant shut-off for cold or warm water lines within the stated pressure and temperature limits. It is not intended for compressed air, aggressive chemicals, or service temperatures outside the 40 to 140 degree range. Buyers needing automated actuation or a different flange pattern should look at other models.

Straightforward wafer installation

The wafer body slides between two mating flanges aligned to the 8-hole, 9 1/2-inch bolt circle and is secured with through-bolts and gaskets. The lever handle mounts directly on the stem per the ISO 5211 top works. Common issues include uneven flange tightening that distorts the PVC body and using gaskets incompatible with EPDM, both of which can cause leaks.

Highlights

  • Handles high pressure with 150 psi rating
  • Operates reliably from 40 to 140 Degrees F
  • Quick manual control via lever handle
  • Durable PVC body with EPDM liner
  • Meets ISO 5211 mounting standard

Specifications

TypeDrain Components
MaterialHAWA
BrandHayward
ModelBYCS1060E1LGA

Questions about this item

What pipe size and bolt pattern must the existing flange match for this 6 in valve to bolt up?

The valve fits a 6 in pipe and requires an 8‑hole flange on a 9 1/2 in bolt circle.

Will the PVC body and EPDM liner handle the same 150 psi pressure and 40 to 140 Degrees F range as my current metal valve?

Yes, the PVC body with EPDM liner is rated for 150 psi maximum water pressure across the full 40 to 140 Degrees F temperature range.

How can I confirm the lever handle is aligned with the disc position after installation?

The lever handle follows ISO 5211 mounting; when the handle is parallel to the pipe the disc is open, and perpendicular means closed.
