Grey PVC bulkhead fitting with female threaded ends

HAYWARD POOL PRODUCTS INC

HAYWARD POOL PRODUCTS INC BFAS1012TFS 1-1/4" Bulkhead Fitting Trap

SKU CH-QNWV-DCBGW MPN BFAS1012TFS

A 1-1/4 inch PVC bulkhead fitting with FKM gasket, rated to 150 psi at 70 degrees F and operating between 40 and 140 degrees F

  • TypeDrain Components
  • ColorGray
  • Female NPT threads on both sides simplify pipe connections
  • Gray PVC body resists corrosion in pool chemical environments
  • FKM gasket seals reliably from 40 to 140 degrees Fahrenheit
  • Rated for 150 psi at 70 degrees Fahrenheit for high-pressure lines
  • Bulkhead design mounts on flat or curved tank walls

Pool Bulkhead Fitting for Plumbing Systems

The Hayward BFAS1012TFS is a 1-1/4 inch bulkhead tank fitting designed for pool and plumbing installations. It connects female NPT threads on both the inside and outside of a tank wall. The gray PVC construction suits curved or flat tank surfaces. It is intended for installers needing a reliable through-wall connection.

Pressure and Temperature Operating Range

The fitting handles a maximum operating pressure of 150 psi at 70 degrees F. It operates within a temperature range of 40 to 140 degrees F. An FKM gasket provides the seal between the fitting and the tank wall. Systems exceeding these pressure or temperature limits require a different specification.

Installation Requirements and Clearance

This fitting threads directly into a tank opening with no bolt holes required. Both connections use 1-1/4 inch female NPT threads for standard pipe adapters. The PVC body and FKM gasket resist common pool chemicals. Installers must verify tank wall thickness and thread compatibility before assembly.

Highlights

  • Female NPT threads on both sides simplify pipe connections
  • Gray PVC body resists corrosion in pool chemical environments
  • FKM gasket seals reliably from 40 to 140 degrees Fahrenheit
  • Rated for 150 psi at 70 degrees Fahrenheit for high-pressure lines
  • Bulkhead design mounts on flat or curved tank walls

Specifications

TypeDrain Components
ColorGray
BrandHayward
ModelBFAS1012TFS

Questions about this item

Will the 1-1/4" FNPT threads on this bulkhead fitting match my existing 1-1/4" schedule 40 PVC plumbing?

Yes, both the inside and outside connections use 1-1/4" female NPT threads, so they will thread directly onto standard 1-1/4" male NPT pipe or adapters.

How can I verify the BFAS1012TFS is sealed correctly after installation?

Pressurise the system up to 150 psi at 70 °F and check the FKM gasket faces for leaks; the fitting is rated for continuous operation between 40 °F and 140 °F.

Does the BFAS1012TFS come with the FKM gasket installed, or do I need to buy one separately?

The FKM gasket is included with the fitting; no separate gasket purchase is required for the bulkhead connection.
