Light gray CPVC bulkhead trap fitting with 1/2 inch FNPT threaded connections

HAYWARD POOL PRODUCTS INC

HAYWARD POOL PRODUCTS INC BFA2005TFS 1/2 in FNPT Bulkhead Trap

SKU CH-MN57-TYW9P MPN BFA2005TFS

1/2 in FNPT bulkhead trap with CPVC body and FKM gasket rated to 150 psi at 70 Degrees F

  • TypeDrain Components
  • MaterialHAWA
  • ColorLight Gray
  • Resists corrosion with CPVC construction
  • Handles pressure up to 150 psi at 70 Degrees F
  • Operates safely from 40 to 190 Degrees F
  • Seals reliably using FKM gasket material
  • Connects easily with 1/2 in FNPT threaded ends

Bulkhead Fitting for Curved and Flat Tanks

The Hayward BFA2005TFS is a CPVC bulkhead tank fitting designed for 1/2 inch FNPT threaded connections on both sides. It suits installers who need a reliable pass-through for plumbing curved or flat tank walls. The light gray body uses an FKM gasket to seal the joint without bolt holes.

Pressure and Temperature Limits

Rated for 150 psi at 70 degrees F, the fitting handles typical residential and light commercial pool circulation pressures. It operates continuously between 40 and 190 degrees F, covering seasonal outdoor temperature swings. The CPVC construction resists corrosion from treated water and common pool chemicals.

Replaces Worn or Leaking Tank Penetrations

This fitting replaces deteriorated bulkheads that leak at the tank wall or seize during service. The upgrade is worth it when the old gasket material has hardened or the threads no longer seal. It restores a secure, tool-tightened connection without modifying existing 1/2 inch pipework.

Highlights

  • Resists corrosion with CPVC construction
  • Handles pressure up to 150 psi at 70 Degrees F
  • Operates safely from 40 to 190 Degrees F
  • Seals reliably using FKM gasket material
  • Connects easily with 1/2 in FNPT threaded ends

Specifications

TypeDrain Components
MaterialHAWA
ColorLight Gray
BrandHayward
ModelBFA2005TFS

Questions about this item

Should I choose the 1/2 in FNPT version or is another size available?

This model is supplied only with 1/2 in FNPT connections on both the inside and outside; no other size is offered for the BFA2005TFS.

What does the 150 psi @ 70 °F rating mean once the fitting is installed?

It indicates the maximum operating pressure the bulkhead can handle when the fluid temperature is 70 °F; at higher temperatures the allowable pressure drops.

How does the FNPT threaded interface limit what I can connect?

Both ports use 1/2 in FNPT threads, so only male NPT fittings or adapters of the same size will seal correctly.
