Dark grey PVC bulkhead fitting with two female threaded ports

HAYWARD POOL PRODUCTS INC

HAYWARD POOL PRODUCTS INC BFA1020TFS 2 in FNPT bulkhead trap

SKU CH-1MF5-Y5707 MPN BFA1020TFS

2-inch FNPT bulkhead trap with PVC body, FKM gasket and 150 psi rating at 70 °F

  • TypeDrain Components
  • MaterialHAWA
  • ColorDark Gray
  • 2-inch FNPT connections simplify tank piping
  • FKM gasket resists chemicals up to 140 °F
  • PVC body rated for 150 psi at 70 °F
  • Operates reliably from 40 °F to 140 °F
  • Dark gray finish suits pool and spa installations

2 in FNPT Bulkhead Trap

The Hayward BFA1020TFS is a PVC bulkhead tank fitting with female National Pipe Thread connections on both the inside and outside. Dark grey in colour, it suits curved or flat tank walls and uses an FKM gasket for sealing. Rated for 150 psi at 70 Degrees F, it operates between 40 and 140 Degrees F. No bolt holes are present on the flange.

Check tank wall and thread compatibility

Verify that the tank opening matches the fitting body and that the wall thickness allows full thread engagement on both sides. Confirm the system pressure never exceeds 150 psi at 70 Degrees F and that fluid temperature stays within the 40 to 140 Degrees F range. Ensure the mating pipes use 2 in FNPT threads and that FKM gasket material is suitable for the media being handled.

FKM gasket and thread style define sealing

The supplied FKM gasket provides chemical resistance that differs from standard EPDM or Buna-N options, affecting long-term seal life with certain fluids. Female threads on both connections mean the fitting accepts male pipe ends directly without separate adapters. The zero bolt-hole design relies entirely on thread tightening and gasket compression for a secure, leak-free joint.

Highlights

  • 2-inch FNPT connections simplify tank piping
  • FKM gasket resists chemicals up to 140 °F
  • PVC body rated for 150 psi at 70 °F
  • Operates reliably from 40 °F to 140 °F
  • Dark gray finish suits pool and spa installations

Specifications

TypeDrain Components
MaterialHAWA
ColorDark Gray
BrandHayward
ModelBFA1020TFS

Questions about this item

Does the Hayward BFA1020TFS bulkhead trap include the FKM gasket or must it be purchased separately?

The fitting ships with an FKM gasket installed, so no separate gasket purchase is required for the 2 in FNPT connections.

When should I choose the 2 in FNPT version over other sizes for my tank?

Select this 2 in FNPT model when both the tank penetration and the plumbing line are 2 in female threaded, matching the inside and outside connection sizes listed.

What does the 150 psi @ 70 °F rating mean for daily pool operation?

It confirms the fitting can handle 150 psi at 70 °F, with a safe operating window from 40 °F up to 140 °F for typical pool temperatures.
