White vandal dome security camera with fixed 3.7 mm lens and IR LEDs

Hanwha Techwin

Hanwha Techwin XNV-8020R 5MP 3.7 mm IR 30 m IP67 IK10

SKU CH-5W85-S7HWF MPN XNV-8020R

A 5 MP outdoor vandal dome with a 3.7 mm fixed lens, 30 m IR range, IP67 and IK10 ratings, and WiseStream II compression

  • 5MP resolution at 30 fps delivers detailed video
  • 7 mm fixed lens provides 97.5° wide coverage
  • 120 dB WDR handles extreme lighting contrasts
  • 30 m IR range enables clear night monitoring
  • IP67 and IK10 ratings protect against weather and vandalism

Network IR Outdoor Vandal Dome Camera

The Hanwha Techwin XNV-8020R is a 5MP network IR outdoor vandal dome camera designed for professional surveillance installations. It captures video at up to 30fps across all resolutions using H.265, H.264 or MJPEG compression. The 3.7 mm fixed lens provides a 97.5 degree horizontal field of view. Built-in IR LEDs deliver illumination up to 98 feet in darkness.

Suited for exposed sites needing rugged 5MP coverage

This unit suits installers who require a single vandal-resistant dome with 120dB WDR and advanced analytics such as loitering, directional detection, sound classification and people counting. Dual SD card slots provide local recording redundancy. Buyers who need a varifocal lens, a different focal length or higher than 5MP resolution should consider other models.

Sustained operation in harsh environments

The camera operates on 12VDC, 24VAC or PoE and meets IP67, IP66 and IK10 ratings plus NEMA 4X for dust, water and impact resistance. Defog detection, digital image stabilisation and hallway view maintain usable footage during prolonged adverse weather or vibration. WiseStream II compression reduces bandwidth and storage load during continuous 30fps streaming.

Highlights

  • 5MP resolution at 30 fps delivers detailed video
  • 7 mm fixed lens provides 97.5° wide coverage
  • 120 dB WDR handles extreme lighting contrasts
  • 30 m IR range enables clear night monitoring
  • IP67 and IK10 ratings protect against weather and vandalism

Specifications

BrandHanwha Techwin
Shipping weight0.91 kg
Package size178 × 178 × 178 mm

Questions about this item

What power source do I need to run the 12VDC/24VAC/PoE camera?

The camera accepts 12 V DC, 24 V AC or Power over Ethernet, so you must provide one of those three supplies.

Will the 3.7 mm fixed lens cover the same area as my old varifocal lens?

The 3.7 mm lens gives a 97.5° horizontal field of view; compare that angle with your previous lens to judge coverage.

How can I verify the IR is reaching the full 30 m at night?

Check the live view after dark — the built-in IR LEDs are rated for 30 m (98 ft) illumination distance.
