Black 19 inch 5:4 IR touch overlay panel with USB cable

Guangzhou Goodtouch Electronics Co.,LTD

Guangzhou Goodtouch Electronics Co.,LTD 19" 5:4 IR Touch Overlay 2-Point USB

SKU CH-1HWN-85393

A 19-inch 5:4 infrared touch overlay adds two-point USB touch to any 19-inch display with driver-free Windows, Linux and Android support

  • Monitor TypeTouchscreen Monitor
  • Cabinet ColorBlack
  • Screen Size19"
  • Touchscreen InterfaceUSB
  • Style2-Point Touch
  • 19" 5:4 IR overlay adds 2-point touch to compatible monitors
  • USB HID interface works driver-free on Windows, Android and Linux
  • 3 mm anti-vandal glass resists damage while keeping 100% light transmission
  • Infrared grid delivers 32768×32768 resolution with 2 mm accuracy at 450 fps
  • Operates up to 3000 m altitude and tolerates 75% sensor damage

19-Inch 5:4 IR Touch Overlay for Existing Displays

This infrared touch overlay adds two-point touch control to a 19-inch 5:4 display. It is built for kiosk, digital-signage and interactive-whiteboard integrators who need a durable touch surface without replacing the underlying monitor. The panel ships with 3 mm anti-vandal glass and operates driver-free on Windows, Linux and Android.

Simple USB HID Installation

The overlay connects through a single USB cable and uses the operating system's built-in HID driver, so no extra software is required on Windows, Linux or Android. Mac OS needs the supplied HID driver installed manually. The unit only fits a 19-inch 5:4 screen; mounting it on any other size or aspect ratio will cause misalignment and touch errors.

Verify Display Size, Aspect Ratio

Confirm that the target monitor is exactly 19 inches with a 5:4 native ratio before ordering. Ensure the host system runs Windows 7 or later, a standard Linux distribution, Android or Mac OS with HID support. Smart-TV Android implementations and Raspberry Pi platforms are not supported by the firmware.

Highlights

  • 19" 5:4 IR overlay adds 2-point touch to compatible monitors
  • USB HID interface works driver-free on Windows, Android and Linux
  • 3 mm anti-vandal glass resists damage while keeping 100% light transmission
  • Infrared grid delivers 32768×32768 resolution with 2 mm accuracy at 450 fps
  • Operates up to 3000 m altitude and tolerates 75% sensor damage

Specifications

Monitor TypeTouchscreen Monitor
Cabinet ColorBlack
Screen Size19"
Touchscreen InterfaceUSB
Style2-Point Touch

Questions about this item

How can I confirm the 19 inch 5:4 ratio IR overlay is working correctly after connecting the USB cable?

The overlay should register up to 2 touch points with an 8 ms response time and operate at up to 450 fps once the USB connection is active.

What components are included with the 19 inch IR touch overlay and what must be sourced separately?

The package contains the overlay panel with 3 mm anti-vandal glass and a USB interface cable; a compatible 19 inch 5:4 display must be purchased separately.

Which version of the overlay matches a 19 inch 5:4 display and provides 2-point touch?

Choose the 19 inch 5:4 ratio model with 2-point touch capability, 32768 x 32768 resolution and 2 mm position accuracy.
