Small white rectangular box with two phone ports and one network port on the back

Grandstream

Grandstream GS-HT802 2-port analog telephone adapter

SKU CH-NQAY-EN9TV MPN GS-HT802

Connects two analogue phones to a VoIP network via dual FXS ports and a single 10/100 Mbps Ethernet link with TLS/SRTP encryption

  • TypeAdapter
  • SpecificationsInterfaces: Telephone Interfaces Two (2) FXS ports Network I
  • FeaturesSupports 2 SIP profiles through 2 FXS ports and a single 10/
  • Connect two analogue phones via dual FXS ports
  • Secure calls with TLS and SRTP encryption
  • Automate setup using TR-069 or XML config files
  • Enable three-way voice conferencing on analogue handsets
  • Transmit faxes over IP with T.38 support

Two FXS ports for analog phones

The Grandstream GS-HT802 connects two standard telephones or fax machines to a VoIP network through its pair of FXS ports. It is aimed at home users and small offices that want to keep existing handsets while moving to SIP telephony. The adapter also suits service providers deploying large-scale IP voice services.

Single 10/100 Mbps Ethernet uplink

A single auto-sensing 10/100 Mbps RJ45 port carries all voice traffic for both lines. This shared uplink is the specification that determines whether the device fits a given network layout; environments requiring gigabit throughput or separate wired paths for each line will need a different solution.

Passive cooling in a compact chassis

The unit runs silently without fans and draws minimal power from its external supply. In normal operation the small enclosure stays cool to the touch, making it suitable for desk or wall mounting in quiet rooms. No thermal throttling or audible noise occurs under typical call loads.

Highlights

  • Connect two analogue phones via dual FXS ports
  • Secure calls with TLS and SRTP encryption
  • Automate setup using TR-069 or XML config files
  • Enable three-way voice conferencing on analogue handsets
  • Transmit faxes over IP with T.38 support

Specifications

BrandGrandstream
ModelGS-HT802
TypeAdapter
SpecificationsInterfaces:
Telephone Interfaces Two (2) FXS ports
Network Interfaces One (1) 10/100 Mbps auto-sensing ethernet ports (RJ45)
LED Indicators POWER, INTERNET, PHONE1, PHONE2
Factory Reset Button Yes
Voice, Fax, Modem:
Telephony Features Caller ID display or block, call waiting, flash, blind or attended transfer, forward,
hold, do not disturb, 3-way conference
Voice Codecs G.711 with Annex I (PLC) and Annex II (VAD / CNG), G.723.1, G.729A/B, G.726, iLBC,
OPUS, dynamic jitter buffer, advanced line echo cancellation
Fax Over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-swit
FeaturesSupports 2 SIP profiles through 2 FXS ports and a single 10/100 Mbps port
TLS and SRTP security encryption technology to protect calls and accounts
Automated provisioning options include TR-069 and XML config files
Supports 3-way voice conferencing
Failover SIP server automatically switches to secondary server if main server loses connection
Supports T.38 Fax for creating Fax-over-IP
Supports a wide range of caller ID formats
Use with Grandstream's UCM series of IP PBXs for Zero Configuration provisioning
Shipping weight0.91 kg
Package size305 × 229 × 110 mm

Questions about this item

What does the 2 FXS ports figure mean for my analog phones?

You can connect two separate analog telephones or fax machines and register each to its own SIP account, so both lines operate independently over the same network connection.

What does the 10/100 Mbps ethernet port cap in practice?

The single RJ45 port negotiates at either 10 or 100 Mbps, so all voice traffic, provisioning data and fax-over-IP share that bandwidth ceiling.

How much space does the adapter need on a desk or wall?

The unit is ultra-compact and designed for desktop placement or wall mounting without requiring a rack shelf or special brackets.
