Black diagnostic cable with grey connectors and green circuit board, includes key induction adapter with LED indicator

GODIAG

GODIAG GT114 Audi K-Line IMMO Cable for A4 A6 C5 2nd 3rd Gen

SKU CH-J8RC-GDACH

Enables offline IMMO synchronization, key matching, data read-write and mileage repair on Audi A4 and A6 C5 dashboards from 2000 to 2006

  • FeaturesGODIAG GT114 Audi K-Lline IMMO cable performs offline key an
  • Performs offline key and IMMO instrument synchronization test
  • Enables intelligent IMMO emergency start area sensing detection
  • Supports IMMO dashboard offline diagnosis and data reading
  • Works with VCDS 5053, VAS5054A and X300 DP Plus
  • Includes independent power and ignition switches for control

Target Vehicles and Core Function

The GODIAG GT114 cable connects Audi A4 and A6 C5 models from 2000 to 2006 to diagnostic tools for immobiliser work. It converts the dashboard connection to standard OBD2 so technicians can read and write instrument IMMO data, repair mileage and match keys offline.

Sustained Diagnostic Use

An independent power switch and separate ignition switch let the operator control voltage during long coding sessions without draining the vehicle battery. The key induction adapter includes a light to confirm coil activity while the tool maintains a stable K-Line link through extended data transfers.

Installation Notes

The package plugs into the dashboard harness and the tester with no soldering required. Successful key matching demands a genuine Megamos ID 48 key because the Xhorse super chip will not complete the process. After reading data the PIN code must be recorded and the generated IMMO file written back before learning can finish.

Highlights

  • Performs offline key and IMMO instrument synchronization test
  • Enables intelligent IMMO emergency start area sensing detection
  • Supports IMMO dashboard offline diagnosis and data reading
  • Works with VCDS 5053, VAS5054A and X300 DP Plus
  • Includes independent power and ignition switches for control

Specifications

BrandGODIAG
FeaturesGODIAG GT114 Audi K-Lline IMMO cable performs offline key and IMMO instrument synchronization test, intelligent IMMO system emergency start area sensing detection, IMMO dashboard offline diagnosis, instrument IMMO data reading and writing, instrument mileage repair, key matching... It supports Audi A6 C5 from 2000-2006.

Questions about this item

Does the GT114 cable draw power from the car or need its own supply while running key-matching tests all day?

The cable has an independent power switch and an independent ignition switch, so it uses vehicle power but gives you manual control over when the dashboard and immobiliser circuits are energised.

Which diagnostic tools must I already own to use the GT114 for offline IMMO data reading and key synchronisation?

It works with HEX V2, VAGCOM VCDS 5053, VAS5054A, VAS6154, SUPER VAG K+CAN, Obdstar, Lonsdor, AVDI, ZEDFULL, VVDI2, Key Tool Plus, X300 DP Plus, SUPER VAG and AUTEL devices.

Can I keep using my existing Megamos ID 48 transponder keys when the GT114 writes new immobiliser data to the dashboard?

Yes — the matching process requires a Megamos ID 48 key, and after the instrument data is written back you perform the normal matching learning with those same keys.
