GE
GE Fusible AC Disconnect Switch 240V 30A
A fusible AC disconnect switch rated 30 A at 240 V AC with a pull-out design and NEMA 3R galvanised steel enclosure
- TypeLight Switch
- Fusible protection for safe AC disconnection
- 30 A rating handles residential air-conditioning loads
- 240 V AC operation matches standard supply
- NEMA 3R galvanised steel enclosure resists weather
- Pull-out design allows quick power isolation
GE Fusible AC Disconnect Switch 240V 30A
This GE fusible AC disconnect switch provides a 240V AC, 30A rated disconnection point for single-phase air conditioning circuits. It uses a pull-out design with Class H fuse protection inside a galvanised steel NEMA 3R enclosure. The unit is cUL and UL listed for outdoor or indoor mounting.
Installers wiring residential
Electricians fitting a 3 hp, 240V single-phase condenser will find the DPST contact form and two-pole, two-wire layout match standard hook-up practice. Builders needing a non-fusible disconnect, a three-phase device or a higher amperage rating must select a different model.
Fusible pull-out protection method
The switch employs a pull-out handle that physically removes the fuse carrier to isolate the circuit. This mechanical action gives a visible break and allows fuse replacement without tools. Specifiers requiring a fixed breaker or non-fusible switch should choose an alternative style.
Highlights
- Fusible protection for safe AC disconnection
- 30 A rating handles residential air-conditioning loads
- 240 V AC operation matches standard supply
- NEMA 3R galvanised steel enclosure resists weather
- Pull-out design allows quick power isolation
Specifications
| Brand | General Electric |
|---|---|
| Type | Light Switch |
Questions about this item
How do I verify the GE fusible AC disconnect switch is operating correctly after installation?
Pull out the handle to open the circuit, confirm the air-conditioning unit stops, then push the handle fully in to close the circuit and verify the unit restarts; the DPST contacts and Class H fuse provide visible isolation.
What components are included with the GE fusible AC disconnect switch and what must be purchased separately?
The switch enclosure with pull-out mechanism and DPST contacts is supplied; Class H fuses rated for 30 A at 240 V AC must be bought separately.
Which version of the GE fusible AC disconnect switch should I select for a 3 hp, 240 V single-phase air-conditioning circuit?
Choose the 30 A, 240 V AC fusible model with NEMA 3R galvanized-steel enclosure, DPST pull-out design and cUL/UL listing for 3 hp motor loads.
