Transparent rectangular GE lighting contactor with four screw terminals and a visible coil block

GE

GE CR463L40AJA 120VAC Lighting Contactor 4P 30A

SKU CH-GDPP-FWFSH

Electrically held lighting contactor rated 30 A inductive with 120 V AC coil and four poles

  • TypeIndustrial Electrical Controls & Automation
  • ColorTransparent
  • Controls LED loads up to 10 A reliably
  • Handles tungsten lighting up to 20 A safely
  • Rated for fluorescent circuits up to 30 A
  • Operates on 110/115-120 V AC coil voltage
  • Provides 1 hp at 120 V AC single-phase

GE CR463L40AJA Lighting Contactor

The GE CR463L40AJA is a four-pole electrically held lighting contactor rated for 30 amps inductive load. It suits commercial and industrial lighting panels that need reliable magnetic switching of fluorescent, LED or tungsten circuits. Installers use it where a 120 VAC coil controls branch circuits without a reversing requirement. The open-frame design fits inside existing enclosures or custom cabinets.

30 A Fluorescent and 20 A Tungsten Ratings

The contactor carries 30 amps for fluorescent lighting and 20 amps for tungsten lighting, with a 10 amp rating for LED loads. At 120 VAC single phase it handles 1 hp, while at 240 VAC single phase it manages 2 hp. The 460 series frame provides these capacities without an integral enclosure, so the installer must provide suitable over-current protection and housing for the application.

120 VAC Coil for Standard Control Circuits

The coil operates on 110 to 120 VAC, matching common control transformers and building automation outputs. Four poles allow switching of multi-phase or multi-circuit loads from a single device. Because the unit ships without an enclosure, the builder must supply a NEMA-rated box and wiring that meets local code. The non-reversing action simplifies wiring for straightforward on/off lighting control.

Highlights

  • Controls LED loads up to 10 A reliably
  • Handles tungsten lighting up to 20 A safely
  • Rated for fluorescent circuits up to 30 A
  • Operates on 110/115-120 V AC coil voltage
  • Provides 1 hp at 120 V AC single-phase

Specifications

BrandGE
TypeIndustrial Electrical Controls & Automation
ColorTransparent

Questions about this item

Will the 120VAC coil on this CR463L40AJA contactor work with my existing 110V or 115V control circuit?

Yes, the coil is rated for 110/115-120V AC, so it will operate reliably on your existing control voltage.

How can I verify the 4-pole contactor is switching my 30A fluorescent lighting load correctly after installation?

Measure the voltage across each of the four pole terminals with the coil energised; all poles should show continuity and pass the 30A fluorescent rating without overheating.

Does the CR463L40AJA come with a NEMA enclosure or mounting hardware, or must I buy those separately?

The unit has no enclosure (open frame) and ships without a NEMA box or mounting brackets; you must supply a suitable enclosure and hardware separately.
