Open-frame motor starter on DIN rail, grey enclosure, transparent cover, three-pole contactor visible

GE

GE CR306C00200XAAAAG Nonreversing NEMA Magnetic Motor Starter

SKU CH-2QWF-E29BC

A non-reversing NEMA magnetic motor starter with electronic overload protection from 6.5 to 13.5 A and a 120 V AC coil

  • TypeNEMA
  • ColorTransparent
  • Non-reversing three-phase starter for simple motor control
  • Electronic overload protection adjustable from 6.5 A to 13.5 A
  • 120 V AC coil voltage matches common control circuits
  • DIN-rail mounting enables quick panel installation
  • 400 NEMA rating confirms industrial-grade construction

Three-phase NEMA starter

The GE CR306C00200XAAAAG is a non-reversing NEMA magnetic motor starter rated for three-phase operation. It handles a maximum of 120V AC coil and line voltage with a 1 1/2 hp rating at 240V AC. Electronic overload protection is adjustable between 6.5 A and 13.5 A. One normally open auxiliary contact is included for control circuit signalling.

DIN rail mounting frees panel space

The unit mounts directly on a DIN rail, eliminating the need for a dedicated enclosure or back-plan drilling. Its open design allows immediate access to wiring terminals and the overload relay adjustment dial. The compact 9.400 NEMA frame leaves room for adjacent contactors or terminal blocks inside the cabinet.

Replaces fixed-heater starters

The electronic overload replaces traditional heater elements, so a single unit covers the full 6.5 A to 13.5 A range without stocking multiple trip classes. The jump is worth it when motor full-load current falls inside that window and you want to reduce spare-part variety. Builders needing reversing duty or higher horsepower at 240V AC must select a different starter.

Highlights

  • Non-reversing three-phase starter for simple motor control
  • Electronic overload protection adjustable from 6.5 A to 13.5 A
  • 120 V AC coil voltage matches common control circuits
  • DIN-rail mounting enables quick panel installation
  • 400 NEMA rating confirms industrial-grade construction

Specifications

BrandGE
ModelCR306C00200XAAAAG
TypeNEMA
ColorTransparent

Questions about this item

How long can the CR306C00200XAAAAG run at its 13.5 A overload setting before the electronic protection trips?

The electronic overload relay is adjustable from 6.5 A to 13.5 A; trip time depends on the overload magnitude and follows the selected curve, so continuous operation at the exact 13.5 A setting will not trip the unit.

What is the coil power draw and resulting heat when the starter is energised all day on 120 V AC?

The 120 V AC coil draws only a few watts once sealed in, so steady-state heat is minimal and the DIN-rail mounted body stays cool to the touch during continuous duty.

Which auxiliary contact block or control-circuit wiring must I already have to use the built-in 1NO contact?

The starter includes one 1NO auxiliary contact rated for the same 120 V AC control circuit; you only need standard panel wiring and a DIN rail to connect it.
