Grey plastic pull-out disconnect switch in a rectangular NEMA 3R enclosure

GE

GE AC Disconnect Switch Non-Fusible 240V 60A

SKU CH-DWXZ-10YKA

Provides 60 A, 240 V AC disconnect for air-conditioning circuits with a pull-out, non-fusible design rated IP14 and NEMA 3R for indoor or outdoor use

  • TypeLight Switch
  • Non-fusible design simplifies installation
  • 60 A rating supports 10 hp motor loads
  • 240 V AC operation suits residential air-conditioning circuits
  • NEMA 3R enclosure rated IP14 for indoor or outdoor mounting
  • cUL and UL listed for code-compliant safety

Product Identity

The GE AC Disconnect Switch is a non-fusible, pull-out safety device rated for 240V AC and 60 amps. It provides a visible means of disconnecting power to outdoor air-conditioning units or similar single-phase loads in residential and light-commercial installations.

Decisive Specification

The switch uses a DPST contact form with a 10 hp motor rating at 240V AC and carries both UL and cUL listings. Buyers who need over-current protection integrated into the disconnect cannot use this non-fusible model and must select a fusible alternative instead.

Sustained-Load Behaviour

The IP14-rated, NEMA 3R plastic enclosure is rated for indoor and outdoor environments, shielding the contacts from rain and splashing water during continuous operation. The pull-out handle gives a clear visual confirmation that the circuit is open, supporting safe maintenance procedures over the equipment’s service life.

Highlights

  • Non-fusible design simplifies installation
  • 60 A rating supports 10 hp motor loads
  • 240 V AC operation suits residential air-conditioning circuits
  • NEMA 3R enclosure rated IP14 for indoor or outdoor mounting
  • cUL and UL listed for code-compliant safety

Specifications

BrandGeneral Electric
TypeLight Switch

Questions about this item

How much motor load can the 10 hp rating actually handle on a 240 V circuit?

The 10 hp rating at 240 V AC means the switch is designed to start and run a single-phase air-conditioning compressor or fan motor up to that horsepower without overheating the contacts.

What does the NEMA 3R enclosure rating allow for outdoor mounting?

NEMA 3R means the plastic housing resists falling rain, sleet and external ice formation, so the disconnect can be surface-mounted outside the building without a separate weatherproof box.

What wiring space and conduit entries does the 7 in by 5 in by 2 in housing provide?

The enclosure measures 7 in high, 5 in wide and 2 in deep, with standard knockout openings on the bottom and sides for 1/2 in or 3/4 in conduit to bring in the two 60 A supply conductors and two load conductors.
