White rectangular document scanner with top paper tray and front output slot, compact desktop form factor

Fujitsu

Fujitsu ScanSnap iX500 PA03656-B015 document scanner

SKU CH-W8TB-349QB MPN PA03656-B015

Duplex scanner with 50-sheet feeder scans 25 pages per minute at 600 dpi via USB 3.0 or Wi-Fi to PC, Mac and mobile devices

  • TypeDuplex
  • Element TypeColor CIS (Contact Image Sensor) x 2 (front / back)
  • Light Source3 Color LED (Red / Green / Blue)
  • Scanning SpeedScanning Speed (A4 portrait): Auto mode: Simplex or Duplex,
  • Optical Resolution600 x 600 dpi
  • Max. Document SizeNormal Mode without Carrier Sheet: A4, A5, A6, B5, B6, Busin
  • Scans 25 pages per minute in duplex mode
  • 50-sheet automatic feeder handles multi-page batches
  • 600 x 600 dpi optical resolution captures fine detail
  • Wi-Fi and USB 3.0 give flexible connectivity
  • Built-in GI microprocessor speeds image processing

Product and audience

The Fujitsu ScanSnap iX500 PA03656-B015 is a duplex document scanner built for PC and Mac users who want to digitise paper quickly. It uses two colour CIS sensors with three-colour LED illumination and a 50-page automatic document feeder. A built-in GI microprocessor handles image processing while USB 3.0 and Wi-Fi give flexible connectivity options.

Suitable and unsuitable users

This scanner suits offices and home workers who need fast double-sided scanning up to 25 ppm and the ability to send files directly to iOS or Android devices. It does not support TWAIN or ISIS drivers on Windows and lacks TWAIN support on Mac, so buyers who rely on those interfaces for specialised capture software should look elsewhere.

Deciding specification

The optical resolution is fixed at 600 x 600 dpi and the ADF accepts a maximum document size of 216.00 mm x 360.00 mm with a 50-page capacity. These figures determine whether the scanner can handle your document dimensions and throughput requirements.

Highlights

  • Scans 25 pages per minute in duplex mode
  • 50-sheet automatic feeder handles multi-page batches
  • 600 x 600 dpi optical resolution captures fine detail
  • Wi-Fi and USB 3.0 give flexible connectivity
  • Built-in GI microprocessor speeds image processing

Specifications

BrandFujitsu
SeriesScanSnap
TypeDuplex
Element TypeColor CIS (Contact Image Sensor) x 2 (front / back)
Light Source3 Color LED (Red / Green / Blue)
Scanning SpeedScanning Speed (A4 portrait):
Auto mode: Simplex or Duplex, 25 pages per minute (ppm)
Normal mode: Color & Grayscale 150 dpi, Monochrome 300 dpi, Simplex / Duplex, 25 ppm
Better mode: Color & Grayscale 200 dpi, Monochrome 400 dpi, Simplex / Duplex, 25 ppm
Best mode: Color & Grayscale 300 dpi, Monochrome 600 dpi, Simplex / Duplex, 25 ppm
Excellent mode: Color & Grayscale 600 dpi, Monochrome 1200 dpi, Simplex / Duplex, 7 ppm
Optical Resolution600 x 600 dpi
Max. Document SizeNormal Mode without Carrier Sheet:
A4, A5, A6, B5, B6, Business Card, Post Card, Letter, Legal and Custom Size
Max: 216.00 mm x 360.00 mm (8.50" x 14.17"), Min: 50.80 mm x 50.80 mm (2.00" x 2.00")
Automatically recognizes document size
Normal Mode with Carrier Sheet:
Use of a Carrier Sheet permits the scanning of A3, B4, 279.40 mm x 431.80 mm (11.00" x 17.00") and photographs as well as the document sizes listed above
Long Paper Scanning:
863.00 mm (34.00")
Paper Weight (thickness):
40.00 g/m2 to 209.00 g/m2 (11.00 lbs. to 56.00 lbs.)
Paper Chute Capacity:
Maximum 50 sheets (A4, 80.0
Automatic Document Feeder (ADF)Yes
ADF Capacity50 Pages
USB PortsUSB 3.0 (USB 2.0 / 1.1 Compatible)
Other PortsWi-Fi Interface:
Observed Standards: IEEE802.11b / IEEE802.11g / IEEE802.11n
Communication Mode: Infrastructure Mode
Frequency: 2.412 GHz to 2.462 GHz / 2.412 GHz to 2.472 GHz
Communication Distance: Indoors, 50.00 m (Recommended: indoors, within 25.00 m)
(May vary depending on surrounding environment and the access point to be connected)
Security: WPA-PSK (TKIP / AES), WPA2-PSK (TKIP / AES), WEP (64-bit / 128-bit)
Easy Installation: WPS2.0 supported (button / PIN code)
Power RequirementsAC 100 - 240V, 50 / 60 Hz
Power ConsumptionUSB connected:
Operating Mode: 20 W or less
Standby Mode: 1.6 W or less (Wi-Fi Switch Off)
Auto Standby (Off) Mode: less than 0.4 W
Wi-Fi connected:
Operating Mode: 20 W or less
Standby Mode: 2.5 W or less
Auto Standby (Off) Mode: less than 0.4 W
Operating Systems SupportedSpecific driver:
Windows: Does not support Twain / ISIS
Mac OS: Does not support Twain
FeaturesFeatures:
Easily Transform Paper with the Touch of a Button
Scan Directly to Mobile Devices
Fast Double-Sided Scanning
Built-in "GI" microprocessor
Advanced Paper Feeding System
Advanced Paper Detection
Accelerated Searchable PDF creation
Productivity Software for PC
More Ways to Scan to the cloud
Dimensions6.60" x 11.50" x 6.20"
Weight6.62 lbs.
Software IncludedScanSnap Manager (Mac) (PC)
ScanSnap Organizer (PC)
ABBY FinerReader (Mac) (PC)
Evernote (Mac) (PC)
Card Minder (Mac) (PC)
Adobe Acrobat X Standard (PC)
Rack2-Filer Smart with Magic Desktop (PC)
Shipping weight4.51 kg
Package size399 × 267 × 246 mm

Questions about this item

What cables and software come with the ScanSnap iX500 and what must I buy separately?

The box includes USB 3.0 connectivity, Wi-Fi interface, ScanSnap Manager for PC and Mac, ScanSnap Organizer, ABBYY FineReader, Evernote, Card Minder, Adobe Acrobat X Standard for PC, and Rack2-Filer Smart with Magic Desktop for PC. No extra cables or software are required for core scanning.

Should I choose the USB 3.0 or Wi-Fi connection for fastest daily scanning?

USB 3.0 delivers the full 25 ppm duplex speed with lower standby power (1.6 W). Wi-Fi uses the same 25 ppm rating but draws 2.5 W standby and is limited to 2.4 GHz 802.11b/g/n indoors up to 50 m.

What does the 600 x 600 dpi optical resolution mean for my scanned PDFs?

It captures fine text detail at 600 dpi; Normal mode scans colour at 150 dpi and monochrome at 300 dpi for 25 ppm throughput, while Better mode raises colour to 200 dpi. Maximum document size is 216 x 360 mm.
